The bq24160, bq24160A, bq24161, bq24161B, bq24163, and bq24168 are highly integrated single cell Li-Ion battery charger and system power path management devices targeted for space-limited, portable applications with high capacity batteries. The single cell charger has dual inputs which allow operation from either a USB port or higher-power input supply (that is, AC adapter or wireless charging input) for a versatile solution. The two inputs are fully isolated from each other and are easily selectable using the I2C interface.
FEATURES
• High-Efficiency Switch Mode Charger with Separate Power Path Control
– Make a GSM Call with a Deeply Discharged Battery or No Battery
– Instantly Start Up System from a Deeply Discharged Battery or No Battery
• Dual Input Charger
• Highly Integrated Battery N-Channel MOSFET Controller for Power Path Management
– 20 V input rating, with Overvoltage Protection (OVP)
– 6.5 V for USB Input
– 10.5 V for IN input (bq24160, bq24160A, bq24161, bq24163)
– 6.5 V for IN input (bq24168)
– Integrated FETs for Up to 2.5A Charge Rate
– Up to 2.5 A from IN Input (input current limit)
– Up to 1.5 A from USB Input (input current limit)
• Safe and Accurate Battery Management Functions
– 0.5% Battery Regulation Accuracy
– 10% Charge Current Accuracy
• Charge Parameters Programmed Using I2C™ Interface
– Charge Voltage, Current, Termination Threshold, Input Current Limit, VINDPM Threshold, Watchdog and Safety Timers (disabled for bq24160A and bq24168)
