PSoC® Development Tools Selector Guide
For the CY8C29x66, CY8C27x43, CY8C24x94, CY8C24x23A, CY8C21x34, and CY8C21x23
There is a Cypress Development kit for every need – from entry-level evaluation and prototyping, to
full-speed, real-time emulation and debugging, to high volume manufacturing programming.
Software
PSoC software is available for free download at http://www.cypress.com.
PSoC Designer
1
At the core of the PSoC development software suite is PSoC
Designer™. Utilized by thousands of PSoC developers, this robust
software has been facilitating PSoC designs for half a decade.
http://www.cypress.com/psocdesigner
There are three subsystems within PSoC Designer:
1. Device Editor: Configure PSoC hardware blocks and
IO, route internal signals, and define system
parameters.
2. Application Editor: Write application code in ‘C’ or
assembly language. (A fully integrated C compiler is
accessible with the purchase of a license.)
3. Debugger: Debug using breakpoints, trace, watch
variables, advanced dynamic event points, and more.
PSoC Express
As the newest a
ddition to the PSoC
xpress™
gle
ches,
Select inputs and outputs (A)
)
)
http://www.cypress.com/psocexpress
PSoC Programmer
ed on the bench in
ming,
from
SoC Programmer is the one-stop programming
development software suite, PSoC E
is the first visual embedded system design
tool that allows a user to create an entire
PSoC project and generate a schematic,
BOM, and data sheet without writing a sin
line of code. Users work directly with
application objects such as LEDs, swit
sensors, and fans.
Define the output’s behavior (B
Simulate the design to verify (C)
Build to generate PSoC HEX file,
BOM, schematic, and datasheet (D
Flexible enough to be us
development, yet suitable for factory program
PSoC Programmer works either as a standalone
programming application or it can operate directly
PSoC Designer or PSoC Express.
P
application for Cypress’ PSoC development tools.
http://www.cypress.com/psocprogrammer
3
2
A
B
C
D
