The HC08AP Family is a member of the low-cost, high-performance M68HC08 Family of 8-bit microcontrollers units (MCUs). All MCUs in this family use the enhanced M68HC08 central processor unit (CPU08) and are available with a variety of modules, memory sizes and types, and package types.HC08APxA are the high speed oscillator version of HC08APx device
MoreLess
## Features
High-performance M68HC08 architecture
* Fully upward-compatible object code with M6805, M146805 and M68HC05 families
* Maximum internal bus frequency:
* 8-MHz at 5V operating voltage
* 4-MHz at 3V operating voltage
* Oscillator Options:
* 32-kHz crystal oscillator clock input
* 32MHz internal phase-lock loop
* RC Oscillator
* Optional continuous crystal oscillator operation in stop mode
* Up to 32K bytes user program FLASH memory with security feature
* Up to 2K bytes of on-chip RAM
* Up to 32 general-purpose input/output (I/O) ports:
* 8 keyboard interrupt with internal pull-up
* 8 pins with direct LED drive
* 6 pins with 25mA current sink
* Two 16-bit, 2-channel timer interface modules
* Timebase module
* Serial Communications Interface Module (SCI)
* Infrared Serial Communications Interface Module (IRSCI)
* Serial Peripheral Interface Module (SPI)
* Multi-Master I²C Interface (MMI²C)
* 8-channel, 10-bit ADC
* Low power design (fully static with stop and wait modes)
