The LM2727 and LM2737 are high-speed, synchronous, switching regulator controllers. They are intended to control currents of 0.7A to 20A with up to 95% conversion efficiencies. The LM2727 employs output over-voltage and under-voltage latch- off. For applications where latch-off is not desired, the LM2737 can be used. Power up and down sequencing is achieved with the power-good flag, adjustable soft-start and output enable features. The LM2737 and LM2737 operate from a low-current 5V bias and can convert from a 2.2V to 16V power rail.
FEATURES
• Input Power from 2.2V to 16V
• Output Voltage Adjustable Down to 0.6V
• Power Good flag, Adjustable Soft-Start and Output Enable for Easy Power Sequencing
• Output Over-Voltage and Under-Voltage Latch-Off (LM2727)
• Output Over-Voltage and Under-Voltage Flag(LM2737)
