* High Performance * fMAX = 400MHz maximum operating frequency * tPD = 2.5ns propagation delay * Up to four global clock pins with programmable clock polarity control * Up to 80 PTs per output * Ease of Design * Enhanced macrocells with individual clock, reset, preset and clock enable controls * Up to four global OE controls * Individual local OE control per I/O pin * Excellent First-Time-FitTM and refit * Fast path, SpeedLockingTM Path, and wide-PT path * Wide input gating (36 input logic blocks) for fast counters, state machines and address decoders * Zero Power (ispMACH 4000Z) and Low Power (ispMACH 4000V/B/C) * Typical static current 10µA (4032Z) * Typical static current 1.8mA (4000C) * 1.8V core low dynamic power * Broad Device Offering * Multiple temperature range support * Commercial: 0 to 90°C junction (Tj) * Industrial: -40 to 105°C junction (Tj) * Automotive: -40 to 130°C junction (Tj) * Easy System Integration * Operation with 3.3V, 2.5V or 1.8V LVCMOS I/O * Operation with 3.3V (4000V), 2.5V (4000B) or 1.8V (4000C/Z) supplies * 5V tolerant I/O for LVCMOS 3.3, LVTTL, and PCI interfaces * Hot-socketing * Open-drain capability * Input pull-up, pull-down or bus-keeper * Programmable output slew rate * 3.3V PCI compatible * IEEE 1149.1 boundary scan testable * 3.3V/2.5V/1.8V In-System Programmable (ISP™) using IEEE 1532 compliant interface * I/O pins with fast setup path
