This driver and receiver pair are designed for high speed interconnects utilizing Low Voltage Differential Signaling (LVDS) technology. The driver translates LVTTL signals to LVDS levels with a typical differential output swing of 350mV and the receiver translates LVDS signals, with a typical differential input threshold of 100mV, into LVTTL levels. LVDS technology provides low EMI at ultra low power dissipation even at high frequencies. This device is ideal for high speed clock or data transfer.
Features
---
|
Greater than 400Mbs data rate
3.3V power supply operation
0.5ns maximum differential pulse skew
2.5ns maximum propagation delay
Low power dissipation
Power-Off protection
100mV receiver input sensitivity
Fail safe protection open-circuit, shorted and terminated conditions
