• −55°C to +125°C operating temperature range • Reliable and robust termination system • EIA 0402, 0603, 0805, 1206, 1210, 1808, 1812, 1825, 2220, and 2225 case sizes • DC voltage ratings of 10 V, 16 V, 25 V, 50 V, 100 V, 200 V and 250 V • Capacitance offerings ranging from 0.5 pF up to 0.47 μF • Available capacitance tolerances of ±0.10 pF, ±0.25 pF, ±0.5 pF, ±1%, ±2%, ±5%, ±10%, and ±20%No piezoelectric noise • Extremely low ESR and ESL • High thermal stability • High ripple current capability • Preferred capacitance solution at line frequencies and into the MHz range • Negligible capacitance change with respect to temperature from −55°C to +125°C • No capacitance change with respect to applied rated DC voltage • No capacitance decay with time • Non-polar device, minimizing installation concerns • SnPb plated termination finish (5% Pb minimum)• Flexible termination option available upon request • Available for other surface mount products, additional dielectrics and higher voltage ratings upon request
