CYBL10X6X Family Datasheet
Programmable Radio-on-Chip With
Bluetooth Low Energy (PRoC BLE)
Cypress Semiconductor Corporation • 198 Champion Court • San Jose, CA 95134-1709 • 408-943-2600
Document Number: 001-90478 Rev. *L Revised March 23, 2017
General Description
PRoC BLE is a 32-bit, 48-MHz ARM
®
Cortex
®
-M0 BLE solution with CapSense
®
, 12-bit ADC, four timer, counter, pulse-width
modulators (TCPWM), thirty-six GPIOs, two serial communication blocks (SCBs), LCD, and I
2
S. PRoC BLE includes a royalty-free
BLE stack compatible with Bluetooth
®
4.1 and provides a complete, programmable, and flexible solution for HID, remote controls,
toys, beacons, and wireless chargers. In addition to these applications, PRoC BLE provides a simple, low-cost way to add BLE
connectivity to any system.
Features
Bluetooth
®
Smart Connectivity
■ Bluetooth 4.1 single-mode device
■ 2.4-GHz BLE radio and baseband with integrated balun
■ TX output power: –18 dBm to +3 dBm
■ Received signal strength indicator (RSSI) with 1-dB resolution
■ RX sensitivity: –89 dBm
■ TX current: 15.6 mA at 0 dBm
■ RX current: 16.4 mA
ARM Cortex-M0 CPU Core
■ 32-bit processor (0.9 DMIPS/MHz) with single-cycle 32-bit
multiply, operating at up to 48 MHz
■ 128-KB flash memory
■ 16-KB SRAM memory
■ Emulated EEPROM using flash memory
■ Watchdog timer with dedicated internal low-speed oscillator
(ILO)
Ultra-Low-Power
■ 1.3-µA Deep-Sleep mode with watch crystal oscillator (WCO)
on
■ 150-nA Hibernate mode current with SRAM retention
■ 60-nA Stop mode current with GPIO wakeup
CapSense
®
Touch Sensing with Two-Finger Gestures
■ Up to 36 capacitive sensors for buttons, sliders, and touchpads
■ Two-finger gestures: scroll, inertial scroll, pinch, stretch, and
edge-swipe
■ Cypress Capacitive Sigma-Delta (CSD) provides best-in-class
SNR (> 5:1) and liquid tolerance
■ Automatic hardware-tuning algorithm (SmartSense™)
Peripherals
■ 12-bit, 1-Msps SAR ADC with internal reference,
sample-and-hold (S/H), and channel sequencer
■ Ultra-low-power LCD segment drive for 128 segments with
operation in Deep-Sleep mode
■ Two serial communication blocks (SCBs) supporting I
2
C
(Master/Slave), SPI (Master/Slave), or UART
■ Four dedicated 16-bit TCPWMs
❐ Additional four 8-bit or two 16-bit PWMs
■ Programmable LVD from 1.8 V to 4.5 V
■ I
2
S Master interface
Clock, Reset, and Supply
■ Wide supply-voltage range: 1.9 V to 5.5 V
■ 3-MHz to 48-MHz internal main oscillator (IMO) with 2%
accuracy
■ 24-MHz external clock oscillator (ECO) without load capaci-
tance
■ 32-kHz WCO
Programmable GPIOs
■ 36 GPIOs configurable as open drain high/low,
pull-up/pull-down, HI-Z, or strong output
■ Any GPIO pin can be CapSense, LCD, or analog, with flexible
pin routing
Programming and Debug
■ 2-pin SWD
■ In-system flash programming support
Temperature and Packaging
■ Operating temperature range: –40 °C to +105 °C
■ Available in 56-pin QFN (7 mm × 7 mm) and 68-ball WLCSP
(3.52 mm × 3.91 mm) packages
PSoC
®
Creator™ Design Environment
■ Easy-to-use IDE to configure, develop, program, and test a
BLE application
■ Option to export the design to Keil, IAR, or Eclipse
Bluetooth Low Energy Protocol Stack
■ Bluetooth Low Energy protocol stack supporting generic
access profile (GAP) Central, Peripheral, Observer, or Broad-
caster roles
❐ Switches between Central and Peripheral roles on-the-go
■ Standard Bluetooth Low Energy profiles and services for
interoperability
❐ Custom profile and service for specific use cases
Not Recommended for New Designs
