PSoC
®
4: PSoC 4XX7_BLE
Family Datasheet
Programmable System-on-Chip (PSoC
®
)
Cypress Semiconductor Corporation • 198 Champion Court • San Jose, CA 95134-1709 • 408-943-2600
Document Number: 001-90479 Rev. *L Revised April 12, 2016
General Description
PSoC
®
4 is a scalable and reconfigurable platform architecture for a family of programmable embedded system controllers with an
ARM
®
Cortex
®
-M0 CPU. It combines programmable and reconfigurable analog and digital blocks with flexible automatic routing. The
PSoC 4XX7_BLE product family, based on this platform, is a combination of a microcontroller with an integrated Bluetooth Low Energy
(BLE), also known as Bluetooth Smart, radio and subsystem (BLESS). The other features include digital programmable logic,
high-performance analog-to-digital conversion (ADC), opamps with comparator mode, and standard communication and timing
peripherals. The PSoC 4XX7_BLE products will be fully upward compatible with members of the PSoC 4 platform for new applications
and design needs. The programmable analog and digital subsystems allow flexibility and in-field tuning of the design.
Features
32-bit MCU Subsystem
■ 48-MHz ARM Cortex-M0 CPU with single-cycle multiply
■ Up to 128 KB of flash with Read Accelerator
■ Up to 16 KB of SRAM
BLE Radio and Subsystem
■ 2.4-GHz RF transceiver with 50- antenna drive
■ Digital PHY
■ Link Layer engine supporting master and slave modes
■ RF output power: –18 dBm to +3 dBm
■ RX sensitivity: –89 dBm
■ RX current: 16.4 mA
■ TX current: 15.6 mA at 0 dBm
■ Received Signal Strength Indication (RSSI): 1-dB resolution
Programmable Analog
■ Four opamps with reconfigurable high-drive external and
high-bandwidth internal drive, comparator modes, and ADC
input buffering capability; can operate in Deep-Sleep mode.
■ 12-bit, 1-Msps SAR ADC with differential and single-ended
modes; channel sequencer with signal averaging
■ Two current DACs (IDACs) for general-purpose or capacitive
sensing applications on any pin
■ Two low-power comparators that operate in Deep-Sleep mode
Programmable Digital
■ Four programmable logic blocks called universal digital blocks,
(UDBs), each with eight macrocells and datapath
■ Cypress-provided peripheral Component library, user-defined
state machines, and Verilog input
Power Management
■ Active mode: 1.7 mA at 3-MHz flash program execution
■ Deep-Sleep mode: 1.3 µA with watch crystal oscillator (WCO)
on
■ Hibernate mode: 150 nA with RAM retention
■ Stop mode: 60 nA
Capacitive Sensing
■ Cypress CapSense Sigma-Delta (CSD) provides best-in-class
SNR (> 5:1) and liquid tolerance
■ Cypress-supplied software component makes
capacitive-sensing design easy
■ Automatic hardware-tuning algorithm (SmartSense™)
Segment LCD Drive
■ LCD drive supported on all pins (common or segment)
■ Operates in Deep-Sleep mode with four bits per pin memory
Serial Communication
■ Two independent runtime reconfigurable serial communication
blocks (SCBs) with reconfigurable I
2
C, SPI, or UART function-
ality
Timing and Pulse-Width Modulation
■ Four 16-bit timer, counter, pulse-width modulator (TCPWM)
blocks
■ Center-aligned, Edge, and Pseudo-random modes
■ Comparator-based triggering of Kill signals for motor drive and
other high-reliability digital logic applications
Up to 36 Programmable GPIOs
■ 7mm × 7mm 56-pin QFN package
■ 3.51 mm × 3.91 mm 68-ball CSP package
■ Any GPIO pin can be CapSense, LCD, analog, or digital
■ Two overvoltage-tolerant (OVT) pins; drive modes, strengths,
and slew rates are programmable
PSoC Creator™ Design Environment
■ Integrated design environment (IDE) provides schematic
design entry and build (with analog and digital automatic
routing)
■ API components for all fixed-function and programmable
peripherals
Industry-Standard Tool Compatibility
■ After schematic entry, development can be done with
ARM-based industry-standard development tools
