CY8C24633
PSoC
®
Programmable System-on-Chip
Cypress Semiconductor Corporation • 198 Champion Court • San Jose, CA 95134-1709 • 408-943-2600
Document Number: 001-20160 Rev. *H Revised September 15, 2014
PSoC
®
Programmable System-on-Chip
Features
■ Powerful Harvard-architecture processor
❐ M8C processor speeds to 24 MHz
❐ 8 × 8 multiply, 32-bit accumulate
❐ low Power at High Speed
❐ 3.0 to 5.25 V operating voltage
❐ industrial temperature range: –40 °C to +85 °C
■ Advanced peripherals (PSoC
®
Blocks)
❐ Four Rail-to-Rail analog PSoC blocks provide:
• Up to 14-bit ADCs
• Up to 8-bit DACs
• Programmable gain amplifiers
• Programmable filters and comparators
❐ Four digital PSoC blocks provide:
• 8- to 32-bit timers and counters, 8- and 16-bit pulse-width
modulators (PWMs)
• CRC and PRS modules
• Full-duplex UART
• Multiple SPI masters or slaves
• Connectable to all GPIO Pins
❐ Complex peripherals by combining blocks
❐ High speed 8-bit SAR ADC optimized for motor control
■ Precision, programmable clocking
❐ Internal ±5% 24/48 MHz oscillator
❐ High accuracy 24 MHz with optional 32 kHz crystal and PLL
❐ Optional external oscillator, up to 24 MHz
❐ Internal oscillator for watchdog and sleep
■ Flexible on-chip memory
❐ 8K flash program storage 50,000 erase/write cycles
❐ 256 bytes SRAM data storage
❐ In-System Serial Programming (ISSP)
❐ Partial flash updates
❐ Flexible protection modes
❐ EEPROM emulation in flash
■ Programmable pin configurations
❐ 25 mA sink on all GPIO
❐ Pull-up, pull-down, high Z, strong, or open drain drive modes
on all GPIO
❐ Up to eight Analog Inputs on GPIO plus two additional analog
inputs with restricted routing
❐ Two 30 mA analog outputs on GPIO
❐ Configurable interrupt on all GPIO
■ Additional system resources
❐ I
2
C slave, master, and multi-master to 400 kHz
❐ Watchdog and sleep timers
❐ User-configurable low voltage detection
❐ Integrated supervisory circuit
❐ On-chip precision voltage reference
■ Complete development tools
❐ Free development Software (PSoC Designer™)
❐ Full-featured In-Circuit Emulator and programmer
❐ Full speed emulation
❐ Complex breakpoint structure
❐ 128KB trace memory
