Energy effi ciency
With a track-record of delivering effi cient and feature-rich digital
power solutions, C2000 Piccolo microcontrollers are fi nely tuned to
drive higher effi ciencies in LED lighting designs, meaning greater
savings on customers’ energy bills and differentiation of lighting
products in an energy-conscious world.
Intelligence
Looking for intelligence in your lighting product without the added cost
of external components? C2000 Piccolo microcontrollers have you
covered. With peripherals such as USB, I
2
C, SPI, CAP and UART, Piccolo
digital control enables advanced functionality such as temperature
monitoring, fault detection, light output tuning, proximity sensing and
more. With the availability of integrated timers, capabilities such as
dimming schedulers and advanced lighting control can easily be
added.
Connectivity
C2000 lighting solutions provide the connectivity and remote control
the market demands, without the cost of an external communications
module. Piccolo microcontrollers enable advanced communications
standards such as power line communications (PLC), DALI, DMX512,
KNX and RF.
Applications
The Piccolo lighting kits are ideal for a range of applications including
outdoor, architectural, entertainment, commercial, industrial, and
automotive.
C2000
™
MCU
LED Lighting Guide
controlSUITE™ software
For C2000 development kit software and information, download
controlSUITE at
www.ti.com/controlSUITE
Single rail, multi-string, DC/DC boost
C2000 MCU lighting advantage
• Portfolio of Piccolo MCUs enable a range of lighting designs from
simple, offl ine lighting designs to remote-connectivity-enabled
adaptive designs
• Digital power software libraries provide the building blocks for
effi cient digital power supply design
• Lighting control and communications software examples and
user guides walk developers through the software and hardware
implementations of LED lighting control and communications
• Hardware reference designs provide various example lighting
implementations from DC/DC designs to AC/DC plus
communications
Multi-rail, multi-string, DC/DC boost Single-rail, multi-string, AC/DC PFC, comms
Enabling industry-leading energy effi ciency, adaptive intelligence and remote connectivity, C2000 Piccolo™
MCUs are lighting the way for the future of LED illumination designs.
