Overview
The P1010RDB is a highly integrated reference design board that can help
shorten your time to market. The reference design is aimed at low-cost networking
applications (with or without trust architecture), wired and wireless access, as well as
industrial and smart energy applications.
This cost-effective board is based on the QorIQ P1010 processor family and contains
leading-edge external components to help you quickly design and implement your
target application. The P1010RDB leverages the P1010 processor and supports
both the full-featured P1010 as well as the more cost-efficient P1014 device.
P1010RDB System Block Diagram
QorIQ
P1010/
P1014
6-Lane
SerDes
eTSEC1
1588
DDR3
(1 GB)
EEPROM RTC
JTAG COP
SD/MMC
USB-to-UART
POR Config
Reset
CPLD
PowerClocking
NAND
Flash (2 GB)
NOR
Flash (32 MB)
SGMII PHY
RJ-45
Header
Header
Header
SPI
Relay
DUAL
SLIC
Type A
RJ-11
RJ-11
FXO
FXS
RJ-11
RJ-45
SGMII PHY
RGMII
x1
x1
x1
SPI
UTMI
x1
ESDHC
UART0
UART1
I
2
C
x1
x1
x32 bits
P1014:16 bits
iSATA
Micro-AB
iSATA
Mini-PCIe
®
Mini-PCIe
CAN
PHY
FlexCAN
RJ-45
RGMII PHY
DAC VCXO
Header
P1014 not available
P1010RDB System Block Diagram
QorIQ Multicore Processor Development
QorIQ P1010/P1014
Reference Design Board
