Crystal Part Numbering Guide
1105 South Ridgeview Road
Olathe, KS 66062
Phone: 913.782.7787
Fax: 913.782.6991
www.ecsxtal.com
Example: P/N ECS-160-20-5PX (Std P/N)
P/N ECS-160-20-5PX-ADN (Custom P/N)
Custom/Value Added Options
*
Discontinued
**
Please consult ECS for available Temp Range options of tight stability crystals.
Note 1: Crystals over 24.000 MHz will be 3rd overtone (if available on data sheet) unless fundamental
mode is requested. An "F" suffix after the package type indicates a fundamental mode i.e. ECS-300-S-1-F
would be a 30.000 MHz Fundamental mode crystal.
- - - -
ECS 160 20 5P AX D
Frequency
Abbreviation
160=16.000 MHz
(See page 2 for list of
std frequencies)
Load
Capacitance
20=20 pF
S=Series
Packaging
TR=Tape
& Reel
Frequency
Tolerance
@ +25°
(
Max)
Blank =Std
A =±25 ppm
J = ±20 ppm
R =±15 ppm
C =±10 ppm
Operating Temperature
Blank =Std
L = -10 ~+70°C
M = -20 ~+70°C
N = -40 ~ +85°C
P = -40 ~ +105°C
S = -40 ~ +125°C
U = -55 ~ +125°C
Frequency
Stability (
Max)
Over Temp (
**
)
Blank =Std
D =±100 ppm
E =±50 ppm
G =±30 ppm
H =±25 ppm
T =±20 ppm
W =±15 ppm
K =±10 ppm
Options
Blank = Std
3IL=3rd In
Line Lead
SL=Sleeved
B=Insulator
3L=3rd Lead
F=Fund (Note 1)
X=
Pb Free/RoHS
ECS INC.
N TR
(Package Suffix) Model Types
(4X) HC-49USX 3.5H
(3X) CSM-3X
(4LX) HC-49USX 2.5H
(1X) HC-49UX
(4VX) HC-49USSX
(5PX) CSM-7X
4.3H
(5PLX) CSM-7X
3.2H
(5PV) CSM-7SSX
2.6H
(5G3X) CSM-7X-3L
(6) ECX-206*
(24) ECX-3TA* (7SX) ECX-3SX
(8X) ECS-3x8X
(9X) ECS-3x9X
(10X) ECS-3x10X
(11) ECX-205*
(12) ECX-12
(13X) ECS-2x6X
(13FLX) ECS-2x6
-FLX
(14X) ECS-1x5X
(14FLX) ECS-1x5-
FLX
(17X) ECX-306X
(18) CSM-12
(19A) ECX-19A
(20A) CSM-8A
(20B) CSM-8B
(20BM) CSM-8M
(21) UM-5
(25) UM-4
(26) ECX-26*
(27) ECX-15
(28A) CSM-4A
(30) ECX-53
(30B) ECX-53B
(32) ECX-31
(33) ECX-32
(34) ECX-315*
(34A) ECX-31A
(34B) ECX-31B
(35) CSM-9
(36) ECX-2236
(37) ECX-1637
(38) ECX-71
(39) ECX-39
(42) ECX-42
(46X) HC-46X
(47) ECX-1247
(22) UM-1
(22SMJ)ECX-UM-1
(23A) ECX-64A
(23B) ECX-64
(23C) ECX-64C
