PRODUCTPREVIEW
AM3359, AM3358, AM3357
AM3356, AM3354, AM3352
www.ti.com
SPRS717D –OCTOBER 2011–REVISED MAY 2012
AM335x ARM
®
Cortex™-A8 Microprocessors (MPUs)
Check for Samples: AM3359, AM3358
1 Device Summary
1.1 Features
1234567
– 32KB of L1 Instruction Cache with Single-
• Highlights
Error Detection (parity)
– 275-MHz, 500-MHz, 600-MHz, or 720-MHz
– 32KB of L1 Data Cache with Single Error-
ARM
®
Cortex™-A8 32-Bit RISC
Detection (parity)
Microprocessor
– 256KB of L2 Cache with Error Correcting
• NEON™ SIMD Coprocessor
Code (ECC)
• 32KB/32KB of L1 Instruction/Data Cache
– 176KB of On-Chip Boot ROM
with Single-Error Detection (parity)
– 64KB of Dedicated RAM
• 256KB of L2 Cache with Error Correcting
Code (ECC) – Emulation/Debug
– mDDR(LPDDR)/DDR2/DDR3 Support • JTAG
– General-Purpose Memory Support (NAND, • Embedded Trace Module
NOR, SRAM, etc.) Supporting Up to 16-bit
• Embedded Trace Buffer
ECC
– Interrupt Controller (up to 128 interrupt
– SGX530 3D Graphics Engine
requests)
– LCD and Touchscreen Controller
• On-Chip Memory (Shared L3 RAM)
– Programmable Real-Time Unit and Industrial
– 64 KB of General-Purpose On-Chip Memory
Communication Subsystem (PRU-ICSS)
Controller (OCMC) RAM
– Real-Time Clock (RTC)
– Accessible to all Masters
– Up to Two USB 2.0 High-Speed OTG Ports
– Supports Retention for Fast Wake-Up
with Integrated PHY
• External Memory Interfaces (EMIF)
– 10/100/1000 Ethernet Switch Supporting Up
– mDDR/DDR2/DDR3 Controller:
to Two Ports
• mDDR: 200-MHz Clock (400-MHz Data
– Serial Interfaces Including:
Rate)
• Two Controller Area Network Ports (CAN)
• DDR2: 266-MHz Clock (532-MHz Data
• Six UARTs, Two McASPs, Two McSPI,
Rate)
and Three I2C Ports
• DDR3: 303-MHz-MHz Clock (606-MHz Data
– 12-Bit Successive Approximation Register
Rate)
(SAR) ADC
• 16-Bit Data Bus
– Up to Three 32-Bit Enhanced Capture
• 1 GB of Total Addressable Space
Modules (eCAP)
• Supports One x16 or Two x8 Memory
– Up to Three Enhanced High-Resolution PWM
Device Configurations
Modules (eHRPWM)
• Supports Retention for Fast Wake-Up
– Crypto Hardware Accelerators (AES, SHA,
– General-Purpose Memory Controller (GPMC)
PKA, RNG)
• Flexible 8/16-Bit Asynchronous Memory
Interface with Up to seven Chip Selects
• MPU Subsystem
(NAND, NOR, Muxed-NOR, SRAM, etc.)
– 275-MHz, 500-MHz, 600-MHz, or 720-MHz
• Uses BCH Code to Support 4-Bit, 8-Bit, or
ARM
®
Cortex™-A8 32-Bit RISC
16-Bit ECC
Microprocessor
• Uses Hamming Code to Support 1-Bit
– NEON™ SIMD Coprocessor
ECC
1
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
2SmartReflex, DSP/BIOS, XDS are trademarks of Texas Instruments.
3Cortex, NEON are trademarks of ARM Ltd or its subsidiaries.
4ARM is a registered trademark of ARM Ltd or its subsidiaries.
5EtherCAT is a registered trademark of EtherCAT Technology Group.
6POWERVR SGX is a trademark of Imagination Technologies Limited.
7All other trademarks are the property of their respective owners.
PRODUCT PREVIEW information concerns products in the formative or design phase of
Copyright © 2011–2012, Texas Instruments Incorporated
development. Characteristic data and other specifications are design goals. Texas
Instruments reserves the right to change or discontinue these products without notice.
