User's Guide
SBAU245A–June 2015–Revised July 2015
ADS86xxEVM-PDK Evaluation Module
ADS86xxEVM-PDK
This user guide describes the operation and usage of the ADS86xx evaluation module (EVM). The
ADS86xx are a family of pin-compatible successive approximation (SAR) analog-to-digital converters
(ADCs) with varying resolution and channel counts designed for integrated data acquisition systems.
Table 1 lists the devices available in the ADS86xx family that are supported by the ADS86xxEVM.
Table 1. Devices Supported By the ADS86xxEVM
Device Description
ADS8698 8-channel, integrated, 18-bit SAR ADC with ALARM
ADS8688A 8-channel, integrated, 16-bit SAR ADC with ALARM
ADS8678 8-channel, integrated, 14-bit SAR ADC with ALARM
ADS8668 8-channel, integrated, 12-bit SAR ADC with ALARM
Windows is a registered trademark of Microsoft Corporation.
SPI is a trademark of Motorola Mobility LLC.
Samtec is a trademark of Samtec Inc.
All other trademarks are the property of their respective owners.
