Evaluation Module for the ADS131A04
Microsoft, Windows are registered trademarks of Microsoft Corporation.
User's Guide
SBAU259–March 2016
Evaluation Module for the ADS131A04
Figure 1. ADS131A04 Evaluation Module
The ADS131A04EVM is an evaluation module kit that provides hardware and software support for
evaluation of the ADS131A04 delta-sigma analog-to-digital converter (ADC). The kit utilizes the
TM4C1294NCPDT processor to communicate with the ADC via SPI and provide communication with a PC
over USB interface. The kit also includes a software application that runs on a PC allowing for register
manipulation and data collection from the ADC.
Table 1. Related Documentation
Device Literature Number
ADS131A04 SBAS590
WARNING
This EVM is not intended for high voltage connections.
Do not connect inputs of this EVM to voltages higher than 5 VAC to
minimize shock hazard.
