This is information on a product in full production.
March 2016 DocID018513 Rev 3 1/32
VND5T100AJ-E
Double channel high-side driver with analog current sense for 24 V
automotive applications
Datasheet
-
production data
Features
• General
– Very low standby current
– 3.0 V CMOS compatible input
– Optimized electromagnetic emission
– Very low electromagnetic susceptibility
– Compliant with European directive
2002/95/EC
– Fault reset standby pin (FR_Stby)
• Diagnostic functions
– Proportional load current sense
– High current sense precision for wide range
currents
– Off-state open-load detection
– Output short to V
CC
detection
– Overload and short to ground latch-off
– Thermal shutdown latch-off
– Very low current sense leakage
• Protection
– Undervoltage shutdown
– Overvoltage clamp
– Load current limitation
– Self limiting of fast thermal transients
– Protection against loss of ground and loss
of V
CC
– Thermal shutdown
– Electrostatic discharge protection
Application
All types of resistive, inductive and capacitive
loads
Description
The VND5T100AJ-E is a monolithic device made
using STMicroelectronics
®
VIPower
®
technology,
intended for driving resistive or inductive loads
with one side connected to ground. Active V
CC
pin voltage clamp protects the device against low
energy spikes.
This device integrates an analog current sense
which delivers a current proportional to the load
current.
Fault conditions such as overload,
overtemperature or short to V
CC
are reported via
the current sense pin.
Output current limitation protects the device in
overload condition. The device latches off in case
of overload or thermal shutdown.
The device is reset by a low level pass on the fault
reset standby pin.
A permanent low level on the inputs and fault
reset standby pin disables all outputs and sets the
device in standby mode.
Max transient supply voltage V
CC
58 V
Operating voltage range V
CC
8 to 36 V
Typ on-state resistance (per ch.) R
ON
100 mΩ
Current limitation (typ) I
LIM
22 A
Off-state supply current I
S
2 µA
(1)
1. Typical value with all loads connected.
PowerSSO-12
www.st.com
