PHP/PHD3055E
TrenchMOS™ standard level FET
Rev. 06 — 25 March 2002 Product data
1. Description
N-channel standard level field-effect power transistor in a plastic package using
TrenchMOS™
1
technology.
Product availability:
PHP3055E in SOT78 (TO-220AB)
PHD3055E in SOT428 (D-PAK).
2. Features
■ Fast switching
■ Low on-state resistance.
3. Applications
■ DC to DC converters
■ Switch mode power supplies.
4. Pinning information
[1] It is not possible to make connection to pin 2 of the SOT428 package.
1. TrenchMOS is a trademark of Koninklijke Philips Electronics N.V.
Table 1: Pinning - SOT78, SOT428 simplified outline and symbol
Pin Description Simplified outline Symbol
1 gate (g)
SOT78 (TO-220AB) SOT428 (D-PAK)
2 drain (d)
[1]
3 source (s)
mb mounting base,
connected to drain (d)
MBK106
12
mb
3
MBK091
Top view
13
mb
2
s
d
g
MBB076
