1 KV30F/KV31F Family
Introduction
KV30 and KV31 MCU families are members of the Kinetis V
series and provide a high-performance solution for 3-phase
BLDC, PMSM and ACIM motor control. Built upon the
ARM
®
Cortex
®
-M4 core operating at 100/120 MHz with DSP
and floating-point unit, features include dual 16-bit analog-to-
digital converters with 835 nS conversion time in 12-bit mode,
multiple motor-control timers, programmable-delay block, 64
KB to 512 KB of flash memory, and an external bus interface.
KV3x MCUs are offered in 100LQFP, 64LQFP, 48LQFP
1
and
32QFN packages. All Kinetis V series MCUs are supported by
a comprehensive enablement suite from Freescale and third-
party resources, including reference designs, software
libraries, and motor configuration tools.
For further information on other Freescale Kinetis
Microcontrollers, go to www.freescale.com/kinetis.
2 Block Diagram
The following figure shows a superset block diagram of the
device. Other devices within the family have a subset of the
features.
1. This package offering is subject to removal.
Freescale Semiconductor
Document Number:KV30FKV31FPB
Product Brief
Rev 1, 3/2014
KV30F and KV31F Family Product
Brief
Supports 120/100MHz devices with 64 KB to 512 KB
Embedded Flash
© 2014 Freescale Semiconductor, Inc.
Preliminary
Contents
1 KV30F/KV31F Family Introduction.........................1
2 Block Diagram..........................................................1
3 Features.....................................................................3
4 Part identification....................................................13
