2004 Microchip Technology Inc. DS21812C-page 1
MCP6291/2/3/4/5
Features
• Gain Bandwidth Product: 10 MHz (typ.)
• Supply Current: I
Q
= 1.0 mA
• Supply Voltage: 2.4V to 5.5V
• Rail-to-Rail Input/Output
• Extended Temperature Range: -40°C to +125°C
• Available in Single, Dual and Quad Packages
• Single with Chip Select (CS
) (MCP6293)
• Dual with Chip Select (CS
) (MCP6295)
Applications
• Automotive
• Portable Equipment
• Photo Diode Pre-amps
• Analog Filters
• Notebooks and PDAs
• Battery-Powered Systems
Available Tools
• SPICE Macro Model (at www.microchip.com)
•FilterLab
®
Software (at www.microchip.com)
Typical Application
Description
The Microchip Technology Inc. MCP6291/2/3/4/5 family
of operational amplifiers (op amps) provide wide
bandwidth for the current. This family has a 10 MHz
gain bandwidth product (GBWP) and a 65° phase
margin. This family also operates from a single supply
voltage as low as 2.4V, while drawing 1 mA (typ.)
quiescent current. In addition, the MCP6291/2/3/4/5
supports rail-to-rail input and output swing, with a
common mode input voltage range of V
DD
+300mV to
V
SS
– 300 mV. This family of operational amplifiers is
designed with Microchip’s advanced CMOS process.
The MCP6295 has a chip select input (CS
) for dual op
amps in an 8-pin package. This device is manufactured
by cascading the two op amps, with the output of op
amp A being connected to the non-inverting input of op
amp B. The chip select input puts the device in a Low
Power mode.
The MCP6291/2/3/4/5 family operates in the Extended
Temperature Range of -40°C to +125°C. It also has a
power supply range of 2.4V to 5.5V.
Package Types
A
B
CS
R
2
C
1
R
1
V
IN
V
OU
T
R
4
R
3
C
2
C
3
R
5
MCP6295
Second-Order Sallen-Key Low-Pass Filter with
an Extra Pole-Zero Pair and a Chip Select.
1
2
3
5
6
7
8
7
6
5
V
IN
_
MCP6291
V
DD
1
2
3
4
-
+
NC
NC
NC
V
IN
+
V
SS
MCP6292
PDIP, SOIC, MSOP
MCP6294
1
2
3
4
14
13
12
11
-
+
-
+
10
9
8
5
6
7
+
-
-
+
PDIP, SOIC, TSSOP
1
2
3
4
8
7
6
5
-
+
-
+
V
OUT
MCP6293
1
2
3
4
8
7
6
5
-
+
V
INA
_
V
INA
+
V
SS
V
OUTA
V
OUTB
V
DD
V
INB
_
V
INB
+
V
SS
V
IN
+
V
IN
_
NC
CS
V
DD
V
OUT
NC
V
OUTA
V
INA
_
V
INA
+
V
DD
V
SS
V
OUTB
V
INB
_
V
INB
+
V
OUTC
V
INC
_
V
INC
+
V
OUTD
V
IND
_
V
IND
+
PDIP, SOIC, MSOP
PDIP, SOIC, MSOP
MCP6295
PDIP, SOIC, MSOP
1
2
3
4
8
7
6
5
+
-
V
INA
_
V
INA
+
V
SS
V
OUTA
/ V
INB
+
V
OUTB
V
DD
V
INB
_
CS
-+
1.0 mA, 10 MHz Rail-to-Rail Op Amp
