Design and specifi cations are each subject to change without notice. Ask factory for the current technical specifi cations before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
SMT Trimmer Potentiometers/EVM3V
– 87 –
E
V
M
3
VSX
0525
B
Product Code Packaging Taper & Resistance
Example : B52=500 액
✽For part number details, Please see page 93.
Type/Structure
12345
6
789101112
1. 4
1.6
0.8
3.2
2.2
1.0
0.9
2.4
(Recommended Land Pattern)
3.1
1.9 1.55
3.75
4
2
Resistance
width 0.6
length 2.1
depth 0.5
Driver Slot
c
b
a
(Circuit diagram)
c
b
a
Resin
1.2
1.9
1.85
1.25 0.9
1.0
2.8
■ Specifi cations
■ Minimum Quantity/Packing Unit
Part Number
Taping
Quantity per reel Packaging quantity
Dia. of reel
(mm)
EVM3V2000 10000
φ
178
Total Resistance Value
Resistance Tolerance
100
액
to 1 M
액
±25 %
Power Rating
Limiting Element Voltage
0.15 W
50 V
Rotation Torque 2 to 10 mN·m
Stopper Strength 15 mN·m min.
Temperature Coeffi cient of Resistance ±250
҂
10
–6
/°C
■ Explanation of Part Numbers
3 mm Square SMT Trimmer Potentiometers
with the rotation stopper
(Cermet, Open Frame Type)
Type:
EVM3V
■ Features
● Rotation stopper featured type
● Automatic adjustment type
● High reliability realized by cermet element
● Ex cel lent mountability
● Conforms to JIS C5260-1:1999
■ Recommended Applications
● Audio/visual, offi ce, and communication equipment
● General electronic equipment
■ Dimensions in mm (not to scale)
● 3-terminal, for Automatic Trimming Adjustment
The standard packaging methods for a reel is
φ
178.
Please contact us, if you would like different packaging methods. (Bulk, Reel of
φ
330, Reel of
φ
380)
Mass (Weight) : 32 mg/pc.
Sep. 201000
●RoHScompliant
