2SC4672
Transistors
1/1
Low Frequency Transistor (50V, 2A)
2SC4672
zFeatures
1) Low saturation voltage, typically VCE (sat) =0.1V at IC/IB =1A /50mA.
2) Excellent DC current gain characteristics.
3) Complements the 2SA1797.
zAbsolute maximum ratings (Ta=25°C)
Parameter Symbol
V
CBO
V
CEO
V
EBO
I
C
P
C
Tj
Tstg
Limits
60
50
6
2
0.5
150
−55~+150
Unit
V
V
V
A (DC)
5
A (Pulse)
∗
W
°C
°C
∗
Single pulse, Pw=10ms
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Collector power dissipation
Junction temperature
Storage temperature
zPackaging specifications and h
FE
Type 2SC4672
MPT3
PQ
T100
1000
Package
h
FE
Code
Basic ordering unit (pieces)
Marking DK
∗
∗
Denotes h
FE
zElectrical characteristics (Ta=25°C)
Parameter Symbol Min. Typ. Max. Unit Conditions
BV
CBO
BVCEO
BVEBO
ICBO
IEBO
VCE(sat)
hFE
fT
Cob
60
50
6
−
−
−
82
−
−
−
−
−
−
−
0.1
−
210
25
−
−
−
0.1
0.1
0.35
270
−
−
V
V
V
µA
µA
V
−
MHz
pF
I
C=50µA
I
C=1mA
I
E=50µA
V
CB=60V
V
EB=5V
I
C/IB=1A/50mA
V
CE=2V, IC=0.5A
V
CE=2V, IE=−0.5A, f=100MHz
VCB=10V, IE=0A, f=1MHz
Collector-base breakdown voltage
Collector-emitter breakdown voltage
Emitter-base breakdown voltage
Collector cutoff current
Emitter cutoff current
Collector-emitter saturation voltage
DC current transfer ratio
Transition frequency
Output capacitance
∗
∗
∗Measured using pulse current.
