The TPD6S300EVM from Texas Instruments is a USB type C overvoltage and IEC ESD protection evaluation module. The TI TPD6S300 evaluation module (EVM) helps designers evaluate the operation and performance of the TPD6S300 device. The TPD6S300 is a single-chip solution for protection of the USB type-C configuration channel (CC), sideband use channel (SBU) and D+/D- data lines. The device provides short to VBUS overvoltage protection up to 22V for CC1, CC2, SBU1 and SBU2 pins to prevent damage caused by a faulty connecter or mechanical twist shorting pins. The TPD6S300 also provides six channels of IEC 61000-4-2 ESD protection for CC1, CC2, SBU1, SBU2, D+/D- (top side) and D+/D- (bottom side) pins of the USB type-C connector.
