* Supply Voltage Range 2.2 V to 3.6 V * 16-Bit RISC Architecture, up to 16.384-MHz System Clock * Power Consumption * Active Mode (AM): All System Clocks Active 275 µA/MHz at 16.384-MHz, 3.0 V, Flash Program Execution (Typical) * Standby Mode (LPM3): Watchdog Timer Active, Full RAM Retention 210 µA at 3.0 V (Typical) * Off Mode (LPM4): Full RAM Retention 70 µA at 3.0 V (Typical) * Shutdown Mode (LPM4.5): 75 nA at 3.0 V (Typical) * Wake Up From Standby Mode in 1 µs * Memories * Up to 32KB of Flash Main Memory * 1KB of Flash Information Memory * Up to of 2KB of RAM * Power Management System * Integrated LDO With 1.8-V Regulated Core Supply Voltage * Supply Voltage Monitor With Programmable Level Detection * Brownout Detector * Built-in Voltage Reference * Temperature Sensor * Clock System * 16.384-MHz Internal DCO * DCO Operation With Internal or External Resistor * External Digital Clock Source * Up to Four 24-Bit Sigma-Delta Analog-to-Digital Converters (ADCs) With Differential PGA Inputs * Two 16-Bit Timers With Three Capture/Compare Registers Each * Enhanced Universal Serial Communication Interfaces (eUSCIs) * eUSCI_A0 * Enhanced UART With Automatic Baud-Rate Detection * IrDA Encoder and Decoder * Synchronous SPI * eUSCI_B0 * Synchronous SPI * I2C * 16-Bit Hardware Multiplier * Serial Onboard Programming, No External Programming Voltage Needed * Programmable Code Protection * On-Chip Emulation Module * Available in 28-Pin TSSOP (PW) and 32-Pin VQFN (RHB) Packages
