* Low Supply Voltage Range: 3.6 V Down to 1.8 V * Ultra-Low Power Consumption * Active Mode (AM): All System Clocks Active 265 µA/MHz at 8 MHz, 3.0 V, Flash Program Execution (Typical) 140 µA/MHz at 8 MHz, 3.0 V, RAM Program Execution (Typical) * Standby Mode (LPM3): Real-Time Clock With Crystal, Watchdog, and Supply Supervisor Operational, Full RAM Retention, Fast Wake-Up: 1.7 µA at 2.2 V, 2.5 µA at 3.0 V (Typical) * Off Mode (LPM4): Full RAM Retention, Supply Supervisor Operational, Fast Wake-Up: 1.6 µA at 3.0 V (Typical) * Shutdown RTC Mode (LPM3.5): Shutdown Mode, Active Real-Time Clock (RTC) With Crystal: 1.24 µA at 3.0 V (Typical) * Shutdown Mode (LPM4.5): 0.78 µA at 3.0 V (Typical) * Wake-Up From Standby Mode in 3 µs (Typical) * 16-Bit RISC Architecture, Extended Memory, up to 25-MHz System Clock * Flexible Power Management System * Fully Integrated LDO With Programmable Regulated Core Supply Voltage * Supply Voltage Supervision, Monitoring, and Brownout * System Operation From up to Two Auxiliary Power Supplies * Unified Clock System * FLL Control Loop for Frequency Stabilization * Low-Power Low-Frequency Internal Clock Source (VLO) * Low-Frequency Trimmed Internal Reference Source (REFO) * 32-kHz Crystals (XT1) * One 16-Bit Timer With Three Capture/Compare Registers * Three 16-Bit Timers With Two Capture/Compare Registers Each * Enhanced Universal Serial Communication Interfaces * eUSCI_A0, eUSCI_A1, and eUSCI_A2: Enhanced UART Supports Auto-Baudrate Detection, IrDA Encoder and Decoder, Synchronous SPI * eUSCI_B0: I2C With Multi-Slave Addressing, Synchronous SPI * Password-Protected RTC With Crystal Offset Calibration and TemperatureCompensation * Separate Voltage Supply for Backup Subsystem * 32-kHz Low-Frequency Oscillator (XT1) * Real-Time Clock * Backup Memory (4 x 16 Bits) * Three 24-Bit Sigma-Delta Analog-to-Digital (A/D) Converters With Differential PGA Inputs * Integrated LCD Driver With Contrast Control for up to 320 Segments in 8-Mux Mode * Hardware Multiplier Supports 32-Bit Operations * 10-Bit 200-ksps A/D Converter * Internal Reference * Sample-and-Hold, Autoscan Feature * Up to Six External Channels, Two Internal Channels, Including Temperature Sensor * Three-Channel Internal DMA * Serial Onboard Programming, No External Programming Voltage Needed * Available in 100-Pin and 80-Pin LQFP Packages
