* Minimize Power Consumption with Ultra-Low Power Dissipation * Operating-Mode Current Drain Sleep-Mode Current Drain * Improve Measurement Quality with Excellent DC/AC Accuracy * 24.0-Bit ENOB at 5sps20.9-Bit Noise-Free Resolution at 10sps19-Bit Noise-Free Resolution at 120sps * 570nVRMS Noise at 10sps, ±3.6VFS Input * 1ppm INL (typ), 10ppm (max) and No Missing Codes * Lower System Cost with Integrated Functionality * Programmable Gain (1 to 16) (MAX11210) * Four SPI-Controlled GPIOs for External Mux Control * Optional Input Buffers on Both Signal and Reference Inputs * > 100dB (min) 50Hz/60Hz Rejection * Increase System Accuracy with Built-In Self Calibration * On-Demand Offset and Gain Self-Calibration and System Calibration * User-Programmable Offset and Gain Registers * Increase System Robustness and Reliability with ±2kV ESD Protection * 2.7V to 3.6V Analog Supply Range * 1.7V to 3.6V Digital and I/O Supply Range * -40°C to 85°C Operating Temperature Range
