The CS8900A is a low-cost Ethernet LAN Controller optimized for the Industry Standard Architecture (ISA) bus and general purpose microcontroller busses. Its highly integrated design eliminates the need for costly external components required by other Ethernet controllers. The
CS8900A includes on-chip RAM, 10BASE-T transmit and receive filters, and a direct ISA-Bus interface with 24 mA Drivers.
FEATURES
Single-Chip IEEE 802.3 Ethernet Controller with Direct ISA-Bus Interface
Maximum Current Consumption = 55 mA (5V Supply)
3V or 5V Operation
Industrial Temperature Range
Comprehensive Suite ofSoftware Drivers Available
Efficient PacketPage™ Architecture Operates in I/O and Memory Space, and as DMA Slave
