Features
• Fast, high-density Field Programmable Gate Arrays
- Densities from 50k to 1M system gates
- System performance up to 200 MHz
- 66-MHz PCI Compliant
- Hot-swappable for Compact PCI
• Multi-standard SelectIO™ interfaces
- 16 high-performance interface standards
- Connects directly to ZBTRAM devices
• Built-in clock-management circuitry
- Four dedicated delay-locked loops (DLLs) for
advanced clock control
- Four primary low-skew global clock distribution
nets, plus 24 secondary local clock nets
• Hierarchical memory system
- LUTs configurable as 16-bit RAM, 32-bit RAM,
16-bit dual-ported RAM, or 16-bit Shift Register
- Configurable synchronous dual-ported 4k-bit
RAMs
- Fast interfaces to external high-performance RAMs
• Flexible architecture that balances speed and density
- Dedicated carry logic for high-speed arithmetic
- Dedicated multiplier support
- Cascade chain for wide-input functions
- Abundant registers/latches with clock enable, and
dual synchronous/asynchronous set and reset
- Internal 3-state bussing
- IEEE 1149.1 boundary-scan logic
- Die-temperature sensor diode
• Supported by FPGA Foundation™ and Alliance
Development Systems
- Complete support for Unified Libraries, Relationally
Placed Macros, and Design Manager
- Wide selection of PC and workstation platforms
• SRAM-based in-system configuration
- Unlimited re-programmability
- Four programming modes
•0.22μm 5-layer metal process
• 100% factory tested
Description
The Virtex FPGA family delivers high-performance,
high-capacity programmable logic solutions. Dramatic
increases in silicon efficiency result from optimizing the new
architecture for place-and-route efficiency and exploiting an
aggressive 5-layer-metal 0.22 μm CMOS process. These
advances make Virtex FPGAs powerful and flexible alterna-
tives to mask-programmed gate arrays. The Virtex family
comprises the nine members shown in Table 1 .
Building on experience gained from previous generations of
FPGAs, the Virtex family represents a revolutionary step
forward in programmable logic design. Combining a wide
variety of programmable system features, a rich hierarchy of
fast, flexible interconnect resources, and advanced process
technology, the Virtex family delivers a high-speed and
high-capacity programmable logic solution that enhances
design flexibility while reducing time-to-market.
0
Virtex™ 2.5 V
Field Programmable Gate Arrays
DS003-1 (v4.0) March 1, 2013
00
Product Specification
R
Table 1: Virtex Field Programmable Gate Array Family Members
Device System Gates CLB Array Logic Cells
Maximum
Available I/O
Block RAM
Bits
Maximum
SelectRAM+™ Bits
XCV50 57,906 16x24 1,728 180 32,768 24,576
XCV100 108,904 20x30 2,700 180 40,960 38,400
XCV150 164,674 24x36 3,888 260 49,152 55,296
XCV200 236,666 28x42 5,292 284 57,344 75,264
XCV300 322,970 32x48 6,912 316 65,536 98,304
XCV400 468,252 40x60 10,800 404 81,920 153,600
XCV600 661,111 48x72 15,552 512 98,304 221,184
XCV800 888,439 56x84 21,168 512 114,688 301,056
XCV1000 1,124,022 64x96 27,648 512 131,072 393,216
