FEATURES
APPLICATIONS
DESCRIPTION
TLV320AIC3007
www.ti.com
..................................................................................................................................................................................................... SLOS619 – APRIL 2009
LOW-POWER STEREO AUDIO CODEC
WITH INTEGRATED MONO CLASS-D AMPLIFIER
• Extensive Modular Power Control
2
• Stereo CODEC with Integrated Mono Class-D • Power Supplies:
Amplifier
– Speaker Amp: 2.7 V – 5.5 V
• High Performance Audio DAC
– Analog: 2.7 V – 3.6 V.
– 93 dBA Signal-to-Noise Ratio (Single
– Digital Core: 1.525 V – 1.95 V
Ended)
– Digital I/O: 1.1 V – 3.6 V
– 16/20/24/32-Bit Data
• Packages: 5 × 5 mm 40-QFN, 0.4 mm Pitch
– Supports Sample Rates From 8 kHz to 96
kHz
– 3D/Bass/Treble/EQ/De-Emphasis Effects
• Portable Navigation Devices
– Flexible Power Saving Modes and
• Digital Still or Video Cameras
Performance are Available
• Cellular Handsets
• High Performance Audio ADC
• Portable Media Players
• General Portable Audio Equipment
– 87 dBA Signal-to-Noise Ratio
– Supports Rates From 8 kHz to 96 kHz
– Digital Signal Processing and Noise
Filtering Available During Record The TLV320AIC3007 is a low power stereo audio
codec with stereo headphone amplifier, and mono
• Seven Audio Input Pins
class-D speaker driver, as well as multiple inputs and
– Programmable as 6 Single-Ended or 3 Fully
outputs programmable in single-ended or fully
Differential Inputs
differential configurations. Extensive register-based
power control is included, enabling stereo 48-kHz
– Capability for Floating Input Configurations
DAC playback as low as 15 mW from a 3.3-V analog
• Multiple Audio Output Drivers
supply, making it ideal for portable battery-powered
– Mono Fully Differential or Stereo
audio and telephony applications.
Single-Ended Headphone Drivers
The record path of the TLV320AIC3007 contains
– Single-Ended Stereo Line Outputs
integrated microphone bias, digitally controlled stereo
• Mono Class-D 1W BTL 8 Ω Speaker Driver
microphone preamplifier, and automatic gain control
(AGC), with mix/mux capability among the multiple
• Low Power Consumption: 15-mW Stereo
analog inputs. Programmable filters are available
48-kHz Playback With 3.3-V Analog Supply
during record which can remove audible noise that
• Ultra-Low Power Mode with Passive Analog
can occur during optical zooming in digital cameras.
Bypass
The playback path includes mix/mux capability from
• Programmable Input/Output Analog Gains
the stereo DAC and selected inputs, through
programmable volume controls, to the various
• Automatic Gain Control (AGC) for Record
outputs.
• Programmable Microphone Bias Level
The TLV320AIC3007 contains three high-power
• Programmable PLL for Flexible Clock
output drivers as well as two single-ended line output
Generation
drivers, and a differential class-D output driver.
• I
2
C™ Control Bus
• Audio Serial Data Bus Supports I
2
S,
Left/Right-Justified, DSP, and TDM Modes
1
