2009-2012 Microchip Technology Inc. DS39970E-page 1
PIC24FJXXXDA1/DA2/GB2/GA3/GC0
1.0 DEVICE OVERVIEW
This document defines the programming specification
for the PIC24FJXXXDA1/DA2/GB2/GA3/GC0 families
of 16-bit microcontrollers (MCUs). This programming
specification is required only for those developing pro-
gramming support for the PIC24FJXXXDA1/DA2/GB2/
GA3/GC0 families. Customers using only one of these
devices should use development tools that already
provide support for device programming.
This specification includes programming specifications
for the following devices:
Topics covered include:
1.0 Device Overview .......................................................1
2.0 Programming Overview of the
PIC24FJXXXDA1/DA2/GB2/GA3/GC0 Families..........2
3.0 Device Programming – ICSP...................................18
4.0 Device Programming – Enhanced ICSP..................33
5.0 The Programming Executive ...................................51
6.0 Device Details.........................................................63
7.0 AC/DC Characteristics and Timing Requirements.........66
• PIC24FJ128DA106 • PIC24FJ256DA106
• PIC24FJ128DA110 • PIC24FJ256DA110
• PIC24FJ128DA206 • PIC24FJ256DA206
• PIC24FJ128DA210 • PIC24FJ256DA210
• PIC24FJ128GB206 • PIC24FJ256GB206
• PIC24FJ128GB210 • PIC24FJ256GB210
• PIC24FJ64GA310 • PIC24FJ128GA310
• PIC24FJ64GA308 • PIC24FJ128GA308
• PIC24FJ64GA306 • PIC24FJ128GA306
• PIC24FJ64GC010 • PIC24FJ128GC010
• PIC24FJ64GC008 • PIC24FJ128GC008
• PIC24FJ64GC006 • PIC24FJ128GC006
PIC24FJXXXDA1/DA2/GB2/GA3/GC0 Families Flash
Programming Specification
