Motorola Semiconductor Engineering Bulletin
EB263
How to Program Chip Selects on Modular Microcontrollers
with a System Integration Module
or a Single-Chip Integration Module
By Sharon Darley
Austin, Texas
Introduction
Modular MCUs with a system integration module (SIM) have 12 chip-
select lines, and those with a single-chip integration module (SCIM)
have nine chip selects. Both modules’
1
chip selects are programmed in
the same fashion.
These chip selects are used to expand the system. A chip-select signal
selects and enables a particular peripheral device or memory chip for
data transfer. The chip selects can also be programmed to generate
data transfer and size acknowledge (DSACK) signals.
The chip-select logic can wait for a certain number of states before
generating the acknowledgment. These states are called wait states.
The wait states are inserted after the S3 cycle of a read or write bus
cycle. A normal bus cycle lasts three clock cycles plus the number of wait
clock cycles. Up to and including 13 wait states can be inserted
automatically by the chip selects.
