LMP7312
www.ti.com
SNOSB32B –MARCH 2010–REVISED MARCH 2013
LMP7312 Precision SPI-Programmable AFE with Differential/Single-Ended Input/Output
Check for Samples: LMP7312
1
FEATURES
DESCRIPTION
The LMP7312 is a digitally programmable variable
2
• Typical Values, T
A
= 25°C, V
+
=5V, V
-
=0V.
gain amplifier/attenuator. Its wide input voltage range
• Gain Bandwidth 1 MHz
and superior precision make it a prime choice for
• Input Voltage Range (G= 0.096 V/V) -15V to
applications requiring high accuracy such as data
+15V
acquisition systems for IO modules in programmable
logic control (PLC). The LMP7312 provides a
• Core Op-Amp Input Offset Voltage 100 µV
differential output to maximize dynamic range and
(Max)
signal to noise ratio, thereby reducing the overall
• Supply Current 2 mA (Max)
system error. It can also be configured to handle
• Gain (Attenuation Mode) 0.096 V/V, 0.192
single ended input data converters by means of the
V
OCM
pin (see Application Section for details). The
V/V0.384 V/V, 0.768 V/V
inputs of LMP7312 can be configured in attenuation
• Gain (Amplification Mode) 1 V/V, 2 V/V
mode to handle large input signals of up to +/- 15V,
• Gain Error 0.035% (Max)
as well as in amplification mode to handle current
• Core Op-Amp PSRR 90 dB (Min) loops of 0-20mA and 4-20mA.The LMP7312 is
equipped with a null switch to evaluate the offset of
• CMRR 80 dB (min)
the internal amplifier. A ensured 0.035% maximum
• Adjustable Output Common Mode 1V to 4V
gain error (for all gains) and a maximum gain drift of
• Temperature Range −40 to 125°C
5ppm over the extended industrial temperature range
(-40° to 125°C) make the LMP7312 very attractive for
• Package 14-Pin SOIC
high precision systems even under harsh conditions.
A low input offset voltage of 100µV and low voltage
APPLICATIONS
noise of 3µVpp give the LMP7312 a superior
• Signal Conditioning AFE
performance. The LMP7312 is fully specified from -
40° to 125°C and is available in SOIC-14 package.
– ±10V; ±5V; 0-5V; 0-10V; 0-20mA; 4-20mA
• Data Acquisition Systems
• Motor Control
• Instrument and Process Control
• Remote Sensing
• Programmable Automation Control
