CYRF69103
Programmable Radio-on-Chip Low Power
Cypress Semiconductor Corporation • 198 Champion Court • San Jose, CA 95134-1709 • 408-943-2600
Document Number: 001-07611 Rev. *J Revised May 19, 2017
Programmable Radio on Chip Low Power
PRoC™ LP Features
■ Single Device, Two Functions
❐ 8-bit Flash based MCU function and 2.4 GHz radio
transceiver function in a single device.
■ Flash Based Microcontroller Function
❐ M8C based 8-bit CPU, optimized for Human Interface
Devices (HID) applications
❐ 256 Bytes of SRAM
❐ 8 Kbytes of Flash memory with EEPROM emulation
❐ In-System reprogrammable
❐ CPU speed up to 12 MHz
❐ 16-bit free running timer
❐ Low power wakeup timer
❐ 12-bit Programmable Interval Timer with interrupts
❐ Watchdog timer
■ Industry leading 2.4 GHz Radio Transceiver Function
❐ Operates in the unlicensed worldwide Industrial, Scientific,
and Medical (ISM) band (2.4 GHz to 2.483 GHz)
❐ DSSS data rates of up to 250 Kbps
❐ GFSK data rate of 1 Mbps
❐ –97 dBm receive sensitivity
❐ Programmable output power up to +4 dBm
❐ Auto Transaction Sequencer (ATS)
❐ Framing CRC and Auto ACK
❐ Received Signal Strength Indication (RSSI)
❐ Automatic Gain Control (AGC)
■ Component Reduction
❐ Integrated 1.8 V boost converter
❐ GPIOs that require no external components
❐ Operates off a single crystal
■ Flexible I/O
❐ 2 mA source current on all GPIO pins. Configurable 8 mA or
50 mA/pin current sink on designated pins
❐ Each GPIO pin supports high impedance inputs, configurable
pull up, open drain output, CMOS/TTL inputs, and CMOS
output
❐ Maskable interrupts on all I/O pins
■ Operating Voltage from 1.8 V to 3.6 V DC
■ Operating Temperature from 0 to 70 °C
■ Pb-free 40-pin QFN Package
■ Advanced Development Tools based on Cypress’s PSoC
®
Tools
Applications
The CYRF69103 PRoC LP is targeted for the following
applications:
■ Wireless HID devices:
❐ Mice
❐ Remote Controls
❐ Presenter tools
❐ Barcode scanners
❐ POS terminal
■ General purpose wireless applications:
❐ Industrial applications
❐ Home automation
❐ White goods
❐ Consumer electronics
❐ Toys
Functional Description
PRoC LP devices are integrated radio and microcontroller
functions in the same package to provide a dual-role single-chip
solution.
Communication between the microcontroller and the radio is
through the radio’s SPI interface.
Not recommended for new designs
