CY22393/CY223931
CY22394
CY22395
Three-PLL Serial-Programmable
Flash-Programmable Clock Generator
Cypress Semiconductor Corporation • 198 Champion Court • San Jose, CA 95134-1709 • 408-943-2600
Document Number: 38-07186 Rev. *L Revised May 17, 2016
Three-PLL Seria l-Programmable Flash-Programmable Clock Generator
Features
■ Three integrated phase-locked loops (PLLs)
■ Ultra wide divide counters (8-bit Q, 11-bit P, and 7-bit post
divide)
■ Improved linear crystal load capacitors
■ Flash programmability with external programmer
■ Field-programmable
■ Low jitter, high accuracy outputs
■ Power management options (Shutdown, OE, Suspend)
■ Configurable crystal drive strength
■ Frequency select through three external LVTTL inputs
■ 3.3 V operation
■ 16-pin TSSOP package
■ CyClocksRT™ software support
Advanced Features
■ Two-wire serial interface for in-system configurability
■ Configurable output buffer
■ Digital VCXO
■ High frequency LVPECL output (CY22394 only)
■ 3.3/2.5 V outputs (CY22395 only)
■ NiPdAu lead finish (CY223931)
Functional Description
The CY22393, CY22394, and CY22395 are a family of parts
designed as upgrades to the existing CY22392 device. These
parts have similar performance to the CY22392, but provide
advanced features to meet the needs of more demanding
applications.
The clock family has three PLLs which, when combined with the
reference, allow up to four independent frequencies to be output
on up to six pins. These three PLLs are completely
programmable.
The CY223931 is the CY22393 with NiPdAu lead finish.
For a complete list of related documentation, click here.
Selector Guide
Part Number Outputs Input Frequency Range Output Frequency Range Specifics
CY22393_C 6 CMOS 8 MHz–30 MHz (external crystal)
1 MHz–166 MHz (reference clock)
Up to 200 MHz Commercial temperature
CY22393_I 6 CMOS 8 MHz–30 MHz (external crystal)
1 MHz–166 MHz (reference clock)
Up to 166 MHz Industrial temperature
CY223931_I 6 CMOS 8 MHz–30 MHz (external crystal)
1 MHz–166 MHz (reference clock)
Up to 166 MHz Industrial temperature
CY22394_C 1 PECL/
4 CMOS
8 MHz–30 MHz (external crystal)
1 MHz–166 MHz (reference clock)
100 MHz–400 MHz (PECL)
Up to 200 MHz (CMOS)
Commercial temperature
CY22394_I 1 PECL/
4 CMOS
8 MHz–30 MHz (external crystal)
1 MHz–150 MHz (reference clock)
125 MHz–375 MHz (PECL)
Up to 166 MHz (CMOS)
Industrial temperature
CY22395_C 4 LVCMOS/ 1
CMOS
8 MHz–30 MHz (external crystal)
1 MHz–166 MHz (reference clock)
Up to 200 MHz (3.3 V)
Up to 133 MHz (2.5 V)
Commercial temperature
CY22395_I 4 LVCMOS/ 1
CMOS
8 MHz–30 MHz (external crystal)
1 MHz–150 MHz (reference clock)
Up to 166 MHz (3.3 V)
Up to 133 MHz (2.5 V)
Industrial temperature
