FN2969.10
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
1-888-INTERSIL or 1-888-468-3774
| Intersil (and design) is a registered trademark of Intersil Americas Inc.
Copyright Intersil Americas Inc. 2002, 2005, 2006. All Rights Reserved
All other trademarks mentioned are the property of their respective owners.
82C55A
CMOS Programmable Peripheral Interface
The Intersil 82C55A is a high performance CMOS version of
the industry standard 8255A and is manufactured using a
self-aligned silicon gate CMOS process (Scaled SAJI IV). It
is a general purpose programmable I/O device which may
be used with many different microprocessors. There are 24
I/O pins which may be individually programmed in 2 groups
of 12 and used in 3 major modes of operation. The high
performance and industry standard configuration of the
82C55A make it compatible with the 80C86, 80C88 and
other microprocessors.
Static CMOS circuit design insures low operating power. TTL
compatibility over the full military temperature range and bus
hold circuitry eliminate the need for pull-up resistors. The
Intersil advanced SAJI process results in performance equal
to or greater than existing functionally equivalent products at
a fraction of the power.
Features
• Pb-Free Plus Anneal Available (RoHS Compliant)
(See Ordering Info)
• Pin Compatible with NMOS 8255A
• 24 Programmable I/O Pins
• Fully TTL Compatible
• High Speed, No “Wait State” Operation with 5MHz and
8MHz 80C86 and 80C88
• Direct Bit Set/Reset Capability
• Enhanced Control Word Read Capability
• L7 Process
• 2.5mA Drive Capability on All I/O Ports
• Low Standby Power (ICCSB). . . . . . . . . . . . . . . . . . .10μA
Ordering Information
PART NUMBERS
TEMP.
RANGE (°C) PACKAGE PKG. DWG. #5MHz
PART
MARKING 8MHz
PART
MARKING
CP82C55A-5 CP82C55A-5 CP82C55A CP82C55A 0 to +70 40 Ld PDIP E40.6
CP82C55A-5Z (Note) CP82C55A-5Z CP82C55AZ (Note) CP82C55AZ 0 to +70 40 Ld PDIP (Pb-free)
IP82C55A IP82C55A -40 to +85 40 Ld PDIP
IP82C55AZ (Note) IP82C55AZ -40 to +85 40 Ld PDIP (Pb-free)
CS82C55A-5* CS82C55A-5 CS82C55A* CS82C55A* 0 to +70 44 Ld PLCC N44.65
CS82C55A-5Z* (Note) CS82C55A-5Z CS82C55AZ* (Note) CS82C55AZ 0 to +70 44 Ld PLCC (Pb-free)
IS82C55A-5* IS82C55A-5 IS82C55A* IS82C55A* -40 to +85 44 Ld PLCC
IS82C55A-5Z* (Note) IS82C55A-5Z IS82C55AZ* (Note) IS82C55AZ -40 to +85 44 Ld PLCC (Pb-free)
CQ82C55A* CQ82C55A* 0 to +70 44 Ld MQFP Q44.10x10
CQ82C55AZ (Note) CQ82C55AZ 0 to +70 44 Ld MQFP (Pb-free)
IQ82C55A* IQ82C55A* -40 to +85 44 Ld MQFP
IQ82C55AZ* (Note) IQ82C55AZ -40 to +85 44 Ld MQFP (Pb-free)
ID82C55A ID82C55A -40 to +85 40 Ld CERDIP F40.6
MD82C55A/B MD82C55A/B -55 to +125
8406602QA 8406602QA SMD#
8406602XA 8406602XA SMD# 44 Ld CLCC J44.A
*Add “96” suffix to part number for tape and reel packaging.
NOTE: Intersil Pb-free products employ special Pb-free material sets; molding compounds/die attach materials and 100% matte tin plate termination
finish, which are RoHS compliant and compatible with both SnPb and Pb-free soldering operations. Intersil Pb-free products are MSL classified at Pb-
free peak reflow temperatures that meet or exceed the Pb-free requirements of IPC/JEDEC J STD-020.
Data Sheet November 16, 2006
