BUF08832
BUF08630
www.ti.com
SBOS535 –OCTOBER 2010
Programmable Gamma-Voltage Generator and High Slew Rate V
COM
with Integrated Two-Bank Memory plus 1/2 AVDD Topology
1
FEATURES
DESCRIPTION
2
• 10-Bit Resolution
The BUF08630 offers eight programmable gamma
channels and one programmable V
COM
channel.
• 8-Channel P-Gamma
• 1-Channel P-V
COM
The final gamma and V
COM
values can be stored in
the on-chip, nonvolatile memory. To allow for
• High Slew Rate V
COM
: 45V/ms
programming errors or liquid crystal display (LCD)
• 16x Rewritable Nonvolatile Memory
panel rework, the BUF08630 supports up to 16 write
• Two Independent Pin-Selectable Memory
operations to the on-chip memory.
Banks
The BUF08630 has two separate memory banks,
• Rail-to-Rail Output:
allowing simultaneous storage of two different gamma
– 300mV Min Swing-to-Rail (10mA)
curves to facilitate switching between gamma curves.
– > 300mA Max I
OUT
All gamma and V
COM
channels offer a rail-to-rail
• Low Supply Current output that typically swings to within 150mV of either
supply rail with a 10mA load. All channels are
• Supply Voltage: 9V to 20V
programmed using a two-wire interface that supports
• Digital Supply: 2V to 5.5V
standard operations up to 400kHz and high-speed
• Two-Wire Interface:
data transfers up to 3.4MHz.
– Supports 400kHz and 3.4MHz
For the complete BUF08630 data sheet, contact your
• 1/2 AVDD Capability TI representative.
RELATED PRODUCTS
APPLICATIONS
FEATURES PRODUCT
• TFT-LCD Reference Drivers
22-channel gamma correction buffer BUF22821
16-channel gamma correction buffer BUF16821
12-channel gamma correction buffer BUF12800
18-/20-channel programmable buffer, 10-Bit, V
COM
BUF20800
18-/20-Channel programmable buffer with memory BUF20820
Programmable V
COM
driver BUF01900
22V supply, traditional gamma buffers BUF11705
High-resolution, fully-programmable LCD bias IC for TV TPS65168
