FEATURES
TSB43DA42, TSB43DB42
SLLS560 – FEBRUARY 2007
IEEE 1394a-2000 CONSUMER ELECTRONICS SOLUTION
• 1394 Features – SRAM-Like 16-Bit Asynchronous Interface
(Supports External DMA Only)
– Integrated 400/200/100 Mbps 2-Port PHY
– PCI Interface (33 MHz) Compliant to PCI
– Compliant to IEEE 1394-1995 and IEEE
Specification Version 2.2 (Supports PCI
1394a-2000 Standards
Slave and Master Function)
– Supports Bus Manager Functions and
• Data Buffers
Automatic 1394 Self-ID Verification
– 3x 4K Byte Isochronous Buffers for Audio
– Separate Asyncchronous Ack FIFOs
and Video Data
Decrease the Ack-Tracking Burden on
External CPU – 2x 2K Byte Asynchronous/Asynchronous
Stream Transmit Buffers
• DTLA Encryption Support for MPEG2-DVB,
DSS, and Audio Data (TSB43DA42 Only) – 2x 2K Byte Asynchronous/Asynchronous
Stream Receive Buffers
– Support for up to Three
Encrypted/Decrypted Streams at One Time – 1x 1K Byte Self-ID Buffer
– Full Ake Performed With Hardware Assist – Insertion Buffers for MPEG2 Packet
Insertion (DAT, PMT, SIT, and DIT)
– Secure Method for Loading DTLA
Information Using Ex-CPU Interface – Programmable Data/Space Available
Indicators for Buffer Flow Control
• Audio and Video Interfaces
• Hardware Packet Formatting for the Following
– Three Configurable High-Speed Data Ports
Standards
for Video Data
– IEC61883-1 (General)
– Two Ports Configurable as Parallel or
Serial – IEC61883-2 (SD-DVCR)
– One Port Serial Only – IEC61883-4 (MPEG2-TS)
– Two Interfaces for Audio Data (Only One – IEC61883-6 (Audio and Music)
Audio Stream Supported at a Time)
– IEC61883-7 (ITU-R BO.1294 System B) –
– 60958 Port DSS
– I2S-Style DAC Interface for PCM Data – Asynchronous Packets
(Two Channel)
– Asynchronous Streams
– Pass-Through Modes for HSDI0 and HSDI1
– PHY Packets (Including Self-IDs)
– Packet Insertion – Two Insertion Buffers
• Additional Features
per HSDI
– JTAG Interface to Support Post-Assembly
– PID Filtering (32 PID Filters per HSDI Port)
Scan of Device I/O – Boundary Scan
• External CPU Interfaces
– Unique Binding Method for Protecting
– Motorola 68K-Style 16-Bit Asynchronous Sensitive Off-Chip Data From Ex-CPU
Interface (Supports External DMA Only) Interface
