User's Guide
SLVU328 – July 2009
TPS61097EVM-498
This user's guide describes the characteristics, operation, and use of the TPS61097EVM-498 evaluation
module (EVM). This EVM demonstrates the Texas Instruments TPS61097 synchronous boost converter.
The input voltage range of the TPS61097 is 0.9 V to 5.5 V, allowing the device to operate from one-cell to
three-cell battery configurations in addition to a single-cell Li-ion battery. This user's guide includes setup
instructions, schematic diagram, bill of materials, and printed-circuit board layout drawings for the EVM.
The TPS61097EVM-498 evaluation module (EVM) helps designers evaluate the operation and
performance of the TPS61097 boost converter. The TPS61097 comes in fixed output voltage versions
described in Table 1 . The board features the small 5-pin SOT-23 package for a small solution size.
Table 1. TPS61097 Fixed Output Options
V
OUT
(V)
EVM Device
Min Max
HPA498-001 TPS61097-18DBVR 1.75 1.85
HPA498-002 TPS61097-27DBVR 2.62 2.78
HPA498-003 TPS61097-30DBVR 2.91 3.09
HPA498-004 TPS61097-33DBVR 3.2 3.4
HPA498-005 TPS61097-50DBVR 4.85 5.15
TPS61097, Synchronous Boost Converter With Low Quiescent Current data sheet (SLVS872 )
This section describes the jumpers and connectors on the EVM as well as how to properly connect, set
up, and use the TPS61097EVM-498.
This is the connection for the leads from the input source. Connect the positive connection to the VIN J1
and the negative connection to the GND J3.
This is the connection for the output of the TPS61097EVM. Connect the positive connection of the load to
the VOUT J4 and the negative connection to the GND J6.
SLVU328 – July 2009 TPS61097EVM-498 1
Submit Documentation Feedback
