1 Introduction
1.1 Background
1.2 Performance Specification Summary
User's Guide
SLVU230A – August 2008 – Revised January 2009
TPS61087EVM
This user's guide describes the characteristics, operation, and use of the TPS61087EVM evaluation
module (EVM). This EVM contains the Texas Instruments 650-kHz/1.2-MHz, 18.5-V step-up DC-DC
converter TPS61087. The user's guide includes EVM specifications, recommended test setup, the
schematic diagram, bill of materials, and the board layout.
Contents
1 Introduction ................................................................................................................... 1
2 Setup and Test Results ..................................................................................................... 2
3 Schematic, Bill of Materials, and Board Layout ......................................................................... 4
List of Figures
1 TPS61087EVM Schematic ................................................................................................. 4
2 Top Assembly Layer ......................................................................................................... 5
3 Top Layer Routing ........................................................................................................... 6
4 Bottom Layer Routing ....................................................................................................... 7
List of Tables
1 Performance Specification Summary ..................................................................................... 1
2 Recommended Compensation Network Values at High/Low Frequency ............................................ 3
3 HPA317A Bill of Materials .................................................................................................. 4
This section contains background information for the TPS61087EVM evaluation module.
This TPS61087EVM uses a TPS61087 boost converter to step up 2.5-V to 6-V input voltages to 15 V. The
goal of the EVM is to facilitate evaluation of the TPS61087 power supply solution. The EVM uses the
TPS61087 adjustable output boost converter and the appropriate feedback components to provide 15 V.
Table 1 provides a summary of the TPS61087EVM performance specifications. All specifications are given
for an ambient temperature of 25 ° C.
Table 1. Performance Specification Summary
SPECIFICATION TEST CONDITIONS MIN TYP MAX UNIT
V
IN
2.5 6 V
V
OUT
(1)
TPS61087EVM, V
IN
= 5 V +/- 2%, I
OUT
< 500 mA, f
SW
= 1.2 MHz 14.7 15 15.3 V
(1)
Min and Max values include 1% resistor tolerance as well as IC reference tolerance.
