1 TMS320DM6433 Digital Media Processor
1.1 Features
TMS320DM6433
Digital Media Processor
www.ti.com
SPRS343C – NOVEMBER 2006 – REVISED JUNE 2008
– 256K-Bit (32K-Byte) L1P Program
• High-Performance Digital Media Processor
RAM/Cache [Flexible Allocation]
(DM6433)
– 640K-Bit (80K-Byte) L1D Data RAM/Cache
– 2.5-, 2-, 1.67-, 1.51-, 1.43-ns ns Instruction
[Flexible Allocation]
Cycle Time
– 1M-Bit (128K-Byte) L2 Unified Mapped
– 400-, 500, -600-, 660-, 700-MHz C64x+™
RAM/Cache [Flexible Allocation]
Clock Rate
• Supports Little Endian Mode Only
– Eight 32-Bit C64x+ Instructions/Cycle
– 3200, 4000, 4800, 5280, 5600 MIPS
• Video Processing Subsystem (VPSS)
– Fully Software-Compatible With C64x
– Front End Provides (Resizer Only):
– Commercial and Automotive (Q or S suffix)
• Resize Images From 1/4x to 4x
Grades
• Separate Horizontal and Vertical Control
– Low-Power Device (L suffix)
– Back End Provides:
• VelociTI.2™ Extensions to VelociTI™
• Hardware On-Screen Display (OSD)
Advanced Very-Long-Instruction-Word (VLIW)
• Four 54-MHz DACs for a Combination of
TMS320C64x+™ DSP Core
– Composite NTSC/PAL Video
– Eight Highly Independent Functional Units
– Luma/Chroma Separate Video
With VelociTI.2 Extensions:
(S-video)
• Six ALUs (32-/40-Bit), Each Supports
– Component (YPbPr or RGB) Video
Single 32-Bit, Dual 16-Bit, or Quad 8-Bit
(Progressive)
Arithmetic per Clock Cycle
• Digital Output
• Two Multipliers Support Four 16 x 16-Bit
– 8-/16-bit YUV or up to 24-Bit RGB
Multiplies (32-Bit Results) per Clock
– HD Resolution
Cycle or Eight 8 x 8-Bit Multiplies (16-Bit
– Up to 2 Video Windows
Results) per Clock Cycle
• External Memory Interfaces (EMIFs)
– Load-Store Architecture With Non-Aligned
Support
– 32-Bit DDR2 SDRAM Memory Controller
With 256M-Byte Address Space (1.8-V I/O)
– 64 32-Bit General-Purpose Registers
• Supports up to 333-MHz (data rate) bus
– Instruction Packing Reduces Code Size
and interfaces to DDR2-400 SDRAM
– All Instructions Conditional
– Asynchronous 8-Bit Wide EMIF (EMIFA)
– Additional C64x+™ Enhancements
With up to 64M-Byte Address Reach
• Protected Mode Operation
• Flash Memory Interfaces
• Exceptions Support for Error Detection
– NOR (8-Bit-Wide Data)
and Program Redirection
– NAND (8-Bit-Wide Data)
• Hardware Support for Modulo Loop
Auto-Focus Module Operation
• Enhanced Direct-Memory-Access (EDMA)
Controller (64 Independent Channels)
• C64x+ Instruction Set Features
• Two 64-Bit General-Purpose Timers (Each
– Byte-Addressable (8-/16-/32-/64-Bit Data)
Configurable as Two 32-Bit Timers)
– 8-Bit Overflow Protection
– Bit-Field Extract, Set, Clear
• One 64-Bit Watch Dog Timer
– Normalization, Saturation, Bit-Counting
• One UART With RTS and CTS Flow Control
– VelociTI.2 Increased Orthogonality
• Master/Slave Inter-Integrated Circuit (I
2
C
– C64x+ Extensions
Bus™)
• Compact 16-bit Instructions
• One Multichannel Buffered Serial Port
• Additional Instructions to Support
(McBSP0)
Complex Multiplies
– I2S and TDM
• C64x+ L1/L2 Memory Architecture
– AC97 Audio Codec Interface
