1 TMS320C6727, TMS320C6726, TMS320C6722 DSPs
1.1 Features
TMS320C6727, TMS320C6726, TMS320C6722
Floating-Point Digital Signal Processors
SPRS268E – MAY 2005 – REVISED JANUARY 2007
• C672x: 32-/64-Bit 300-MHz Floating-Point DSPs • Three Multichannel Audio Serial Ports
– Transmit/Receive Clocks up to 50 MHz
• Upgrades to C67x+ CPU From C67x™ DSP
– Six Clock Zones and 16 Serial Data Pins
Generation:
– Supports TDM, I2S, and Similar Formats
– 2X CPU Registers [64 General-Purpose]
– DIT-Capable (McASP2)
– New Audio-Specific Instructions
– Compatible With the C67x CPU
• Universal Host-Port Interface (UHPI)
– 32-Bit-Wide Data Bus for High Bandwidth
• Enhanced Memory System
– Muxed and Non-Muxed Address and Data
– 256K-Byte Unified Program/Data RAM
– 384K-Byte Unified Program/Data ROM
• Two 10-MHz SPI Ports With 3-, 4-, and 5-Pin
– Single-Cycle Data Access From CPU Options
– Large Program Cache (32K Byte) Supports
• Two Inter-Integrated Circuit (I2C) Ports
RAM, ROM, and External Memory
• Real-Time Interrupt Counter/Watchdog
• External Memory Interface (EMIF) Supports
• Oscillator- and Software-Controlled PLL
– 100-MHz SDRAM (16- or 32-Bit)
• Applications:
– Asynchronous NOR Flash, SRAM (8-,16-, or
– Professional Audio
32-Bit)
• Mixers
– NAND Flash (8- or 16-Bit)
• Effects Boxes
• Enhanced I/O System
• Audio Synthesis
– High-Performance Crossbar Switch
• Instrument/Amp Modeling
– Dedicated McASP DMA Bus
• Audio Conferencing
– Deterministic I/O Performance
• Audio Broadcast
• dMAX (Dual Data Movement Accelerator)
• Audio Encoder
Supports:
– Emerging Audio Applications
– 16 Independent Channels
– Biometrics
– Concurrent Processing of Two Transfer
– Medical
Requests
– Industrial
– 1-, 2-, and 3-Dimensional
• Commercial or Extended Temperature
Memory-to-Memory and
Memory-to-Peripheral Data Transfers
• 144-Pin, 0.5-mm, PowerPAD™ Thin Quad
– Circular Addressing Where the Size of a Flatpack (TQFP) [RFP Suffix]
Circular Buffer (FIFO) is not Limited to 2
n
• 256-Terminal, 1.0-mm, 16x16 Array Plastic Ball
– Table-Based Multi-Tap Delay Read and
Grid Array (PBGA) [GDH and ZDH Suffixes]
Write Transfers From/To a Circular Buffer
