TMS320C6712D
FLOATING-POINT DIGITAL SIGNAL PROCESSOR
SPRS293B -- OCTOBER 2005 -- REVISED JUNE 2006
1
POST OFFICE BOX 1443 HOUSTON, TEXAS 77251--1443
D Low-Price/High-Performance Floating-Point
Digital Signal Processor (DSP):
TMS320C6712D
-- Eight 32-Bit Instructions/Cycle
-- 150-MHz Clock Rate
-- 6.7-ns Instruction Cycle Time
-- 900 MFLOPS
D Advanced Very Long Instruction Word
(VLIW) C67x DSP Core
-- Eight Highly Independent Functional
Units:
-- Four ALUs (Floating- and Fixed-Point)
-- Two ALUs (Fixed-Point)
-- Two Multipliers (Floating- and
Fixed-Point)
-- Load-Store Architecture With 32 32-Bit
General-Purpose Registers
-- Instruction Packing Reduces Code Size
-- All Instructions Conditional
D Instruction Set Features
-- Hardware Support for IEEE
Single-Precision and Double-Precision
Instructions
-- Byte-Addressable (8-, 16-, 32-Bit Data)
-- 8-Bit Overflow Protection
-- Saturation
-- Bit-Field Extract, Set, Clear
-- Bit-Counting
-- Normalization
D L1/L2 Memory Architecture
-- 32K-Bit (4K-Byte) L1P Program Cache
(Direct Mapped)
-- 32K-Bit (4K-Byte) L1D Data Cache
(2-Way Set-Associative)
-- 512K-Bit (64K-Byte) L2 Unified Mapped
RAM/Cache
(Flexible Data/Program Allocation)
D Device Configuration
-- Boot Mode: 8- and 16-Bit ROM Boot
-- Little Endian, Big Endian
D Enhanced Direct-Memory-Access (EDMA)
Controller (16 Independent Channels)
D 16-Bit External Memory Interface (EMIF)
-- Glueless Interface to Asynchronous
Memories: SRAM and EPROM
-- Glueless Interface to Synchronous
Memories: SDRAM and SBSRAM
-- 256M-Byte Total Addressable External
Memory Space
D Two Multichannel Buffered Serial Ports
(McBSPs)
-- Direct Interface to T1/E1, MVIP, SCSA
Framers
-- ST-Bus-Switching Compatible
-- Up to 256 Channels Each
-- AC97-Compatible
-- Serial-Peripheral-Interface (SPI)
Compatible (Motorola)
D Two 32-Bit General-Purpose Timers
D Flexible Software-Configurable PLL-Based
Clock Generator Module
D A Dedicated General-Purpose Input/Output
(GPIO) Module With 5 Pins
D IEEE-1149.1 (JTAG
†
)
Boundary-Scan-Compatible
D 272-Pin Ball Grid Array (BGA) Package
(GDP and ZDP Suffix)
D CMOS Technology
-- 0.13-m/6-Level Copper Metal Process
D 3.3-V I/Os, 1.20
‡
-V Internal
