April 2012 Doc ID 022713 Rev 1 1/69
UM1510
User manual
STM32L152D-EVAL demonstration firmware
Introduction
This user manual describes the demonstration firmware running on the STM32L152D-EVAL
evaluation board, which can be used to evaluate the capabilities of the STM32L152ZD(T6)
microcontroller and on-board peripherals.
This demo contains many applications that can be easily reused, such as RTC calendar, file
system FAT implementation on SD Card, Wave player with STM32 I2S peripheral, voice
recording, automatic measure of the power consumption in several operating modes, Dual
Interface EEPROM applications (ESL and DataLogger), temperature sensor interfacing and
TFT LCD.
The STM32L152D-EVAL board is delivered with the demonstration programmed in the
internal Flash memory, and all the files needed by the demonstration are programmed in the
MicroSD card. The demonstration is executed at each reset (board power-up, external reset,
etc.).
In case the STM32L152D-EVAL board was not factory-programmed or the demonstration
application was erased, the Bootloader, IAP or USB DFU can be used to program this file.
For more details, refer to Section 3: STM32L152D-EVAL demonstration package and
Section 4: STM32L152D-EVAL demonstration programming.
Note: Before you execute the demonstration, make sure that all EVAL board jumpers are well
configured. For more details, refer to Section 1.10.11: STM32L152D-EVAL board jumper
configuration.
This demonstration firmware and other such firmware are available for download from the
STMicroelectronics website: www.st.com.
