UG361: Si70xx Evaluation Tools User's
Guide
All of the supported evaluation kits contain the following items:
• Si7013USB-DONGLE evaluation board consisting of one Si7013 sensor as well as
USB interface and circuitry for evaluation of the Si7013 with thermistor or other ana-
log input
• 3-foot flat cable to connect the “postage stamp” boards to the USB dongle
• USB extender cable
• Windows graphical user interface software for complete control of the Si70xx sensors
Depending on the kit, different postage stamp boards are supplied as well.
•
The Si7013USB-Dongle kit has Si7013,Si7020, and Si7021 I
2
C postage stamp
boards.
• The Si7022-23-EVB kit contains Si7022 and Si7023 PWM output boards.
• The Si7006-07-EVB kit contains Si7006 and Si7007 low-cost postage stamp boards.
• The Si7050/1/3/4/5-EVB kits contain the appropriate Si7050, Si7051, Si7053, Si7054,
or Si7055 temperature sensor postage stamp.
• The Si7034 kit contains the Si7034 postage stamp.
• The Si7057-EVB kit contains an Si7057 postage stamp.
The GUI and USB dongle support both PWM output and I
2
C output devices.
KEY FEATURES OR KEY POINTS
This user’s guide describes the evaluation
GUI and PCB board design for the following
evaluation kits:
• Si7013USB-DONGLE kit for Si7013,
Si7020, and Si7021
• Si7022-23-EVB kit for Si7022 and Si7023
• Si7006-07-EVB kit for Si7006 and Si7007
• Si7050/1/3/4/5-EVB kits for Si7050,
Si7051, Si7053, Si7054, and Si7055
temperature sensors
• Si7034-EVB kit
• Si7057-EVB kit for Si7057, Si7058, and
Si7059 temperature sensors
• Si7060-EVB kit
