QorIQ multicore
processor
development
The QorIQ P1020 reference design board (RDB) can help shorten your time to market
for networking, wired and wireless access, industrial and medical applications.
P1020/P1011 Reference
Design Board
The cost-effective, highly integrated board is based on
the QorIQ P1020 processor and leading-edge external
components to help you quickly design and implement
your target application.
The P1020RDB leverages the P1020 processor and supports
both the dual-core P1020 and single-core P1011 configurations.
The P1020 processor family is based on the e500 core, built on
Power Architecture
®
technology, which has a core frequency
range of 533–800 MHz, and supports a 32 KB instruction and
L1 data cache as well as a shared 256 KB frontside cache. The
P1020 also supports three Gigabit Ethernet controllers with
IEEE
®
1588 v2 support, USB 2.0, up to two PCI Express
®
1.0a
controllers, up to two SGMII SerDes interfaces, 32-bit DDR2/3
with ECC, SPI controller supporting booting from SPI serial flash
memory, SD/MMC card controller supporting booting from flash
cards and an integrated security engine. The P1020, built in 45
nm process technology, provides high integration that simplifies
board design and offers a cost-effective solution.
The P1020RDB platform features 1 GB unbuffered DDR3
SDRAM, 16 MB NOR flash and 32 MB NAND flash, where the
platforms can boot from either NOR or NAND flash memory.
It supports six Gigabit-capable ports via an SGMII PHY, an
RGMII PHY and an on-board switch with four ports, as well as
two ports of USB On-the-Go (OTG), four FXS ports and one
FXO port via relay.
The P1020RDB also supports a PCI Express add-in connector
and a MiniPCI Express slot, as well as an SD/MMC card
slot. These components, integrated with the P1020, provide
an application-specific platform that can help you get a
jump start on your next application design. In addition, the
P1020RDB provides a simplified migration path for existing
PowerQUICC processor customers wishing to migrate to
QorIQ multicore processors. Customers can migrate to
the single-core P1011 as a stepping stone on their way to
multicore processing.
Since the P1020 is pin-compatible with the P2020, the
P1020RDB can also be used as a development vehicle
for the P2020.
Along with hardware support, the P1020RDB comes with a board
support package (BSP) that includes both U-boot and Linux
®
2.6 operating system support. The platform is also available
with third-party software applications. To see demonstrations
or to acquire details of our third-party applications for this
platform, please contact your local sales office.
