User's Guide
SBAU190A–May 2011– Revised June 2011
PCM510xEVM-U
The PCM510x family of ICs are advanced segment, high-performance, hardware-programmable stereo
digital-to-analog converters (DACs). These devices employ internal line drivers together with an internal
PLL and BCLK reference, so that a serial clock signal (SCK) can be derived. The advanced segment
architecture enables excellent dynamic performance and improved tolerance to clock jitter, and the
2.1-V
RMS
ground-centered outputs eliminate the need for output dc blocking capacitors. The
PCM510xEVM-U is designed to support the PCM5100, PCM5101, and PCM5102 DACs. The
PCM510xEVM-U also employs the TAS1020B USB controller and the SRC4392 asynchronous sample
rate converter.
This user’s guide describes the operation of the PCM510xEVM-U and the Texas Instruments
CodecControl software. CodecControl provides a graphical user interface for supported TI audio codecs.
The software is compatible with Microsoft
®
Windows
®
XP, Vista, and Windows 7.
Contents
1 Introduction .................................................................................................................. 2
2 PCM510xEVM-U ............................................................................................................ 3
3 CodecControl Software ..................................................................................................... 9
4 Schematics and Bill of Materials ........................................................................................ 14
List of Figures
1 PCM510xEVM-U............................................................................................................ 3
2 PCM510xEVM-U Block Diagram.......................................................................................... 4
3 EVM Software Window ................................................................................................... 10
4 Command Dialog .......................................................................................................... 12
Microsoft, Windows are registered trademarks of Microsoft Corporation.
I
2
S, I
2
C are trademarks of NXP Semiconductors.
TOSLink is a trademark of Toshiba Corporation.
All other trademarks are the property of their respective owners.
