NFM3DPC223R1H3_ (1205, 22000pF, DC50V)
_: packaging code Reference Sheet
1.Scope
2.MURATA Part NO. System
(Ex.)
3. Type & Dimensions
a)Equivalent Circuit
(Unit:mm)
4.Rated value
5.Package
Product specifications in this catalog are as of Mar.3,2016,and are subject to change or obsolescence without notice.
Please consult the approval sheet before ordering.
Please read rating and !Cautions first.
Insulation
Resistance
mark
Packaging Unit
(7) Packaging
This product specification is applied to Chip EMIFIL®Chip 3-terminal Capacitor for Large Current used for General Electronic equipment.
(3) Nominal
Capacitance
Capacitance
Tolerance
(5)
DC Rated
Voltage
Rated
Current
(mA)
i
1.1±0.3
j
0.25±0.2
Chip EMIFIL®Chip 3-terminal Capacitor for Large Current for General
Specifications and Test Methods
(Operating /Storage Temp. Range)
-55 to 125 °C / -55 to 125 °C
±20 %
2ADCat85℃/0.5ADCat125℃
Rdc1:50mΩmax.Rdc2:100mΩmax.
22000 pF
DC
Resistance
1000MΩmin.
DC 50 V
(1)-1 L
(1)-2 W
T
e
g
L
f180mm Reel
EMBOSSED W8P4
4000 pcs./Reel
3.2±0.2
1.25±0.2
0.7±0.2
0.3±0.2
0.4 min.
(1)L/W
Dimensions
(2)Features
(3)Nominal
Capacitance
(4)Temperature
Characteristics
(5)DC Rated
Voltage
(6)Electrode
(7)Packaging
Code
NFM 3D PC 223 R 1H 3 L
NFM3DPC223R1H3-01 1
