NFM31PC276B0J3_ (1206, 27uF, DC6.3V)
_: packaging code Reference Sheet
1.Scope
2.MURATA Part NO. System
(Ex.)
3. Type & Dimensions
a)Equivalent Circuit
(Unit:mm)
4.Rated value
5.Package
Product specifications in this catalog are as of Feb.9,2016,and are subject to change or obsolescence without notice.
Please consult the approval sheet before ordering.
Please read rating and !Cautions first.
Chip EMIFIL®Chip 3-terminal Capacitor for Large Current for General
Specifications and Test Methods
(Operating /Storage Temp. Range)
-40 to 85 °C / -40 to 85 °C
±20 %
6A(DC)
5mΩmax.
27 uF
mark
Packaging Unit
(7) Packaging
i
1.1±0.3
j
0.3±0.2
This product specification is applied to Chip EMIFIL®Chip 3-terminal Capacitor for Large Current used for General Electronic equipment.
(3) Nominal
Capacitance
Capacitance
Tolerance
(5)
DC Rated
Voltage
Rated
Current
(mA)
DC
Resistance
20MΩmin.
DC 6.3 V
Insulation
Resistance
(1)-1 L
(1)-2 W
T
e
g
L
f180mm Reel
EMBOSSED W8P4
3000 pcs./Reel
3.2±0.2
1.6±0.2
1.3±0.2
0.4±0.3
0.3 min.
(1)L/W
Dimensions
(2)Features
(3)Nominal
Capacitance
(4)
Characteristics
(5)DC Rated
Voltage
(6)Electrode
(7)Packaging
Code
NFM 31 PC 276 B 0J 3 L
NFM31PC276B0J3-01 1
