Freescale Semiconductor Document Number: MPL3115A2STUG
User’s Guide Rev. 0, 04/2012
MPL3115A2 Sensor Toolbox
User’s Guide
1 Introduction
The Freescale DEMOSTBMPL3115A2 Sensor Toolbox
provides the hardware and software for demonstrating
the capability of the MPL3115A2 pressure sensor.
The kit includes the following:
• A daughter board KITSTBMPL3115A2 with the
MPL3115A2 pressure sensor
• The LFSTBEBMPL3115A2 evaluation board to
which the daughter board is attached
• The USB-interface board LFSTBUSB for
connecting the evaluation board to a PC’s USB
port
• The DEMOSTBMPL3115A2 Quick Start Guide
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2 Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.1 Assembling the Kit. . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.2 Installing the Sensor Toolbox Software. . . . . . . . . . 3
2.3 Launching the Sensor Toolbox Software. . . . . . . . . 6
2.4 MPL3115A2 Main Screen . . . . . . . . . . . . . . . . . . . . 7
2.5 Registers Screen (For Advanced Users Only) . . . 17
2.6 Related Documentation. . . . . . . . . . . . . . . . . . . . . 17
