Freescale Semiconductor
User Guide
Document Number:
TWRS08GW64UG
Contents
© Freescale Semiconductor, Inc., 2010. All rights reserved.
1 Overview
The MC9S08GW64 Tower MCU Module
(TWR-S08GW64) is a low-cost evaluation,
demonstration and development board. The
TWR-S08GW64 can operate stand-alone or as the main
control board in a Tower System with peripheral
modules.
The following list summarizes the features of the
TWR-S08GW64:
• Tower compatible microcontroller module
• MC9S08GW64 in an 80 LQFP package
• MC9S08JM60 based Open Source Debug
(OSBDM) circuit
• 3 user controlled LEDs
• 3 push buttons and two unpopulated headers for
user input
• 3 pin header for PCNT based sensors
• Potentiometer
1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2 Reference Documents. . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3 Hardware Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.1 Clocking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.2 System Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.3 Debug Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.4 RS232 Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.5 Elevator Connections . . . . . . . . . . . . . . . . . . . . . . . 4
3.6 Mechanical Form Factor . . . . . . . . . . . . . . . . . . . . . 4
4 Jumper Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
5 Input/Output Pin Usage Table . . . . . . . . . . . . . . . . . . . . . 5
Appendix ASilk Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Appendix BSchematic Drawings . . . . . . . . . . . . . . . . . . . . . . . 8
TWR-S08GW64 User Guide
